BF250 D XCDS (BBNJ) - Honda Marine Engine, Made in Japan (SN: BBNJ-8000001 - BBNJ-9999999) EXHAUST MANIFOLD @THERMOSTAT Parts Diagram

Marine Engine, Made in Japan

EXHAUST MANIFOLD @THERMOSTAT Parts Diagram

  • Title

1

Honda 12155-ZV5-000

METAL, ANODE
(Superseded to 12155-ZV5-010)

$14.99

$

In Stock, only 1 left!

0

2

Honda 18110-ZVL-000ZA

MANIFOLD, R. EX. *NH8* (DARK GRAY)

$192.99

$

Usually ships in 3-6 days

0

3

Honda 18115-ZY3-003

GASKET, R. EX. MANIFOLD

$49.99

$

Usually ships in 3-6 days

0

4

Honda 18120-ZVL-000ZA

MANIFOLD, L. EX. *NH8* (DARK GRAY)

$192.99

$

Usually ships in 3-6 days

0

5

Honda 18125-ZY3-003

GASKET, L. EX. MANIFOLD

$49.99

$

Usually ships in 3-6 days

0

6

Honda 19255-ZVL-020

TUBE, R.

$4.49

$

Usually ships in 3-6 days

0

7

Honda 19256-ZY3-010

SEE PART DETAILS - PRI; TUBE, WATER RELIEF

$7.49

$

Usually ships in 3-6 days

0

8

Honda 19257-ZY3-000

TUBE, WATER

$

$

Not available

9

Honda 19261-ZY3-000

TUBE, L. WATER RETURN

$

$

Not available

10

Honda 19300-ZX2-003

THERMOSTAT ASSY.

$61.99

$

Usually ships in 3-6 days

0

11

Honda 19303-ZX2-003

RUBBER, RING

$10.99

$

Usually ships in 3-6 days

0

12

Honda 19313-ZVL-000ZA

SPACER, THERMOSTAT COVER *NH8* (DARK GRAY)
(Superseded to 19313-ZVL-010ZA)

$

$

Not available

12

Honda 19313-ZVL-010ZA

SPACER *NH8*

$

$

Not available

13

Honda 19315-ZVL-000ZA

COVER, THERMOSTAT *NH8* (DARK GRAY)
(Superseded to 19315-ZVL-010ZA)

$35.99

$

Usually ships in 3-6 days

0

13

Honda 19315-ZVL-010ZA

COVER *NH8*

$35.99

$

Usually ships in 3-6 days

0

14

Honda 35673-ZY3-003

SENSOR ASSY., WATER TEMPERATURE

$35.99

$

Usually ships in 3-6 days

0

15

Honda 90019-ZZ5-M00

BOLT, FLANGE (6X35)
(Superseded to 90019-ZZ5-M01)

$3.99

$

In Stock, only 3 left!

0

15

Honda 90019-ZZ5-M01

BOLT, FLANGE (6X35)

$3.99

$

In Stock, only 3 left!

0

16

Honda 90027-ZY9-M01

BOLT, FLANGE (8X60)

$4.49

$

Usually ships in 3-6 days

0

17

Honda 90034-ZVL-010

BOLT, FLANGE (6X60)

$1.99

$

Usually ships in 3-6 days

0

18

Honda 90055-ZZ5-M01

BOLT, FLANGE (8X40)

$2.99

$

Usually ships in 3-6 days

0

19

Honda 90601-ZY3-030

CLAMP, TUBE (D10.5) (ENGINE NO.)

$2.99

$

Usually ships in 3-6 days

0

20

Honda 90603-ZY3-020

CLAMP, TUBE (D29)

$5.99

$

Usually ships in 3-6 days

0

21

Honda 90604-ZY3-020

SEE PART DETAILS - PRI; CLAMP, TUBE (D21)

$3.99

$

Usually ships in 3-6 days

0

22

Honda 91301-ZY3-003

O-RING (66.4X3.1)

$13.99

$

Usually ships in 3-6 days

0

23

Honda 91307-PNA-003

O-RING (9.5X1.9)

$3.49

$

Usually ships in 3-6 days

0

24

Honda 91356-SD4-952

O-RING (31.5X2.4) (ARAI)

$5.49

$

Usually ships in 3-6 days

0

25

Honda 90004-ZX2-000

BOLT, FLANGE (6X18)

Note: Use from Engine SN 1002439.

$2.99

$

Usually ships in 3-6 days

0

25

Honda 93500-06018-4J

SCREW, PAN (6X18)

Note: Use up to Engine SN 1002438.

$2.49

$

In Stock, Qty 5

0

26

Honda 90601-ZVL-000

CLAMP D12.5, TUBE

Note: Use from Engine SN 1011759.

$2.49

$

Usually ships in 3-6 days

0

26

Honda 90601-ZY3-030

CLAMP, TUBE (D10.5) (ENGINE NO.)

Note: Use up to Engine SN 1011758.

$2.99

$

Usually ships in 3-6 days

0
