BP 400 - Poulan Pro Backpack Blower Engine Assembly Parts Diagram

Backpack Blower

Engine Assembly Parts Diagram

  • Title

2

Poulan 110052133

Cylinder

$

$

Not available

3

Poulan 110092521

Gasket

$2.49

$

In Stock, only 1 left!

0

4

Poulan 110602350

Gasket

$

$

Not available

5

Poulan 140022239

Crankcase

$

$

Not available

6

Poulan 140022240

Crankcase
(Superseded to 530058378)

$

$

Not available

7

Poulan 920452005

Bearing

$

$

Not available

8

Poulan 920492076

Oil Seal

$

$

Not available

9

Poulan 530058381

Bolt

$

$

Not available

10

214b0608

Screw

$

$

Not available

11

223b0630

Screw

$

$

Not available

12

551a0610

Dowel Pin

$

$

Not available

13

751q0600

Gasket

$

$

Not available

14

Poulan 130012121

Piston

$

$

Not available

15

Poulan 130022065

Piston Pin

$

$

Not available

16

Poulan 530094023

Piston Ring Set

$

$

Not available

17

Poulan 530058389

Crankshaft Assy.

Note: (Incl. #18)

$

$

Not available

18

Poulan 530094027

Needle Bearing

$

$

Not available

19

Shim

$

$

Not available

19

Poulan 920252134

Shim 0.10mm

$

$

Not available

19

Poulan 920252135

Shim 0.20mm

$

$

Not available

19

Poulan 530094030

Shim 0.40mm

$

$

Not available

19

Poulan 530058394

Shim 0.60mm

$

$

Not available

20

Poulan 920332058

Snap Ring

$

$

Not available

21

Poulan 490892298

Shroud-Heat Shield

$

$

Not available

22

Poulan 530058397

Bolt
(Superseded to 921512063)

$

$

Not available

23

Poulan 490062051

Boot

$

$

Not available

24

Poulan 530058399

Flywheel

$

$

Not available

25

Poulan 530094085

Spark Plug Cap

$

$

Not available

26

Poulan 530094086

Terminal

$

$

Not available

27

Poulan 530089445

Ignition Coil Assy.

$

$

Not available

28

Poulan 260112321

Leadwire

$

$

Not available

29

Poulan 920222147

Washer

$

$

Not available

30

Poulan 920382078

Key

$

$

Not available

31

Poulan 920592233

Tube

$

$

Not available

32

Poulan 530058407

Spark Plug

$3.99

$

In Stock, Qty 20+

0

33

Poulan 920712077

Grommet

$

$

Not available

34

Poulan 530094080

Bolt

$

$

Not available

35

314r1000

Nut

$

$

Not available

36

Poulan 490882380

Assy-Recoil Starter

$

$

Not available

37

Poulan 130702064

Rope Guide

$

$

Not available

38

Poulan 131692386

Plate

$

$

Not available

39

Poulan 320992210

Recoil Starter Case

$

$

Not available

40

Poulan 530058415

Recoil Spring
(Superseded to 921442038)

$

$

Not available

41

Poulan 530058416

Grip

$

$

Not available

42

Poulan 591012085

Pulley

$

$

Not available

43

Poulan 591062117

Rope

$

$

Not available

44

Poulan 920092218

Screw

$

$

Not available

45

Poulan 922002019

Washer

$

$

Not available

46

Poulan 920092285

Screw

$

$

Not available

47

Poulan 530058422

Screw

$

$

Not available

48

Poulan 490802155

Starter Pulley

$

$

Not available

49

Poulan 131652070

Pawl

$3.99

$

In Stock, only 2 left!

0

50

Poulan 920332010

Snap Ring

$

$

Not available

51

Poulan 921442046

Return Spring
(Superseded to 531003367)

$

$

Not available

52

315b0800

Nut

$

$

Not available

53

410b0800

Washer

$

$

Not available

54

Poulan 490892370

Shroud

$

$

Not available
