CCT 400 (41AERP3C912) - CORE by Cub Cadet String Trimmer, Electric (2016) General Assembly Parts Diagram

String Trimmer, Electric

General Assembly Parts Diagram

  • Title

1

Cub Cadet 753-08568

POWER SLEEVE ASSEMBLY

$38.99

$

Usually ships in 3-6 days

0

2

Cub Cadet 753-08420

BOOM ASSEMBLY W/WIRES CGT400 CORE

$56.99

$

Usually ships in 3-6 days

0

3

Cub Cadet 753-08406

HANDLE ASSEMBLY CORE

$

$

Not available

4

Cub Cadet 753-08418

CONTROLER CGT400 CORE

$

$

Not available

5

Cub Cadet 753-08567

POWER HOUSING ASSEMBLY

$60.99

$

Usually ships in 3-6 days

0

6

Cub Cadet 753-08566

ELITE GRIP ASSEMBLY

$55.99

$

Usually ships in 3-6 days

0

7

Cub Cadet 753-08421

GUARD ASSEMBLY W/BLD CORE

$

$

Not available

8

Cub Cadet 753-08422

BUMPHEAD ASSEMBLY COMP CORE

$

$

Not available

9

Cub Cadet 753-08431

BLADE ASSEMBLY CORE

$

$

Not available

10

Cub Cadet 753-08413

HARNESS PHS WIRE CGT400 CORE

$34.99

$

Usually ships in 3-6 days

0

11

Cub Cadet 753-08414

HARNESS HALL WIRE CGT400 CORE

$

$

Not available

12

Cub Cadet 753-08419

MOTOR ASSEMBLY CGT400 CORE

$289.99

$

Usually ships in 3-6 days

0

13

Cub Cadet 753-08410

YOKE ASSEMBLY CGT400 CORE

$22.99

$

Usually ships in 3-6 days

0

14

Cub Cadet 725-06466

CORE BATTERY 18.5V
(Superseded to 490-280-C004)

$

$

Not available

15

Cub Cadet 753-08485

CHARGER 21V 7AH CRC8000 CORE
(Superseded to 490-280-C005)

$

$

Not available
