CH 4400 - Bear Cat 4" Chipper, 400cc Subaru (SN: 5VJAA0017DW000001 - 5VJAA0115HW005384) Housing (VIN: 5VJAA0019EW004199 - CURRENT) Parts Diagram

4" Chipper, 400cc Subaru

Housing (VIN: 5VJAA0019EW004199 - CURRENT) Parts Diagram

  • Title

1

Bear Cat 14768-00

SNAP RING, 1-1/4 EXT. HEAVY DUTY

$7.99

$

Usually ships in 3-7 days

0

2

Bear Cat 14769-00

BUSHING, SDS 1-1/4"

$71.99

$

Usually ships in 3-7 days

0

3

Bear Cat 15049

NUT, 1/2" CENTERLOCK GRB ZP

$0.99

$

Usually ships in 3-7 days

0

4

15057

BOLT, 3/8 X 1" CRG GR5 NC ZP

$

$

Not available

5

15205

BOLT, 3/8 X 5" GR5 HEX CPS ZP

$

$

Not available

6

Bear Cat 15220-00

BOLT, 1/2 X 1-1/2 CRG SN GR5 ZP

$6.49

$

Usually ships in 3-7 days

0

7

Bear Cat 15250

WASHER, 5/16" FLAT ZP

$

$

Not available

8

15300

BOLT, 5/16 X 5/8 GR5 HEX CPS ZP

$

$

Not available

9

Bear Cat 15418

KEY, 1/4 SQ X 1-1/2 LG PLAIN

$

$

Not available

10

Bear Cat 15904-00

NUT, 5/16-18 NYLOCK-FLANGE

$

$

Not available

11

Bear Cat 15905-00

NUT, 3/8-16 NYLOCK FLANGE

$

$

Not available

12

Bear Cat 16001

SHEAVE, 2B 6.6 SDS

$157.99

$

Usually ships in 3-7 days

0

13

Bear Cat 16682

BEARING 1-1/4" DIA 2 BOLT FLNG

$

$

Not available

14

Bear Cat 32963-00

WELDMENT, 4-1/2 CHIPPER DISK
(Superseded to 77797-00)

$1098.99

$

Usually ships in 3-7 days

0

15

Bear Cat 70026-00

ASSEMBLY, ROTOR COVER

Note: (INCLUDES ITEM 16)

$

$

Not available

16

Bear Cat 17913

DECAL, ECHO BEARCAT 6.82 X 1.90

$6.49

$

Usually ships in 3-7 days

0

17

Bear Cat 74529-00

ANVIL, CHIPPER

$57.99

$

Usually ships in 3-7 days

0

18

Bear Cat 74571-12

WELDMENT, CHIP DEFLECTOR

$

$

Not available

19

Bear Cat 77766-35

PLATE, BOLT ACCESS COVER

$

$

Not available

20

Bear Cat 77768-00

ASSEMBLY, CHIPPER HOUSING

Note: (INCLUDES ITEMS 21-24)

$776.99

$

Usually ships in 3-7 days

0

21

Bear Cat 12172

DECAL, OPERATING INSTRUCTIONS ISO

$7.99

$

Usually ships in 3-7 days

0

22

Bear Cat 12250

DECAL, MAINTENANCE ISO

$3.99

$

Usually ships in 3-7 days

0

23

Bear Cat 31466-00

DECAL, MODEL CH4400

$8.99

$

Usually ships in 3-7 days

0

24

Bear Cat 32392-00

DECAL, ECHO BEARCAT QR CODE

$3.49

$

Usually ships in 3-7 days

0
