CZT 72 x (967943501-00) - RedMax 72" Zero-Turn Riding Mower (2018-07) WHEELS & TIRES Parts Diagram

72" Zero-Turn Riding Mower

WHEELS & TIRES Parts Diagram

  • Title

1

RedMax 510154602

TIRE 13X6.5-6 NO FLAT GLOSS BL

$318.99

$

Usually ships in 3-10 days

0

2

RedMax 591091701

TIRE 24X12-12 NHS TURFSMART GL

$423.99

$

Usually ships in 3-10 days

0

3

RedMax 539101474

ZERK

$3.99

$

Usually ships in 3-10 days

0

4

RedMax 510034001

CAP, DUST
(Superseded to 510034003)

$2.49

$

In Stock, Qty 8

0

5

RedMax 525611905

FORK CASTER SNAPPER RED X672

$265.99

$

Usually ships in 3-10 days

0

6

RedMax 590704901

SPACER.HUB

$

$

Not available

7

RedMax 590690701

SPACER.AXLE

$

$

Not available

8

RedMax 510034301

SEAL, BEARING

$6.49

$

In Stock, only 3 left!

0

9

RedMax 510034403

CONE, LM67048

$14.99

$

In Stock, only 2 left!

0

10

RedMax 539105517

HEX SCREW 1/2-13 X 9.5 GR5
(Superseded to 594946501)

$6.49

$

In Stock, Qty 20+

0

11

RedMax 521991101

NUT, 1/2-13 HEX FLG NYLOC ZD
(Superseded to 521991102)

$3.99

$

In Stock, Qty 20+

0

12

RedMax 522842601

NUT, 3/4-16 HEX THIN NYLOC ZD
(Superseded to 522842602)

$3.99

$

In Stock, only 4 left!

0

13

RedMax 587653902

NUT.1/2-20.UNF-2B.GR.8.YL
(Superseded to 587653903)

$3.99

$

In Stock, Qty 20+

0

14

RedMax 539990250

WASHER 1/2" FLAT
(Superseded to 595086801)

$3.99

$

In Stock, Qty 20+

0

15

RedMax 574824701

WASHER, 3/4 HARDENED
(Superseded to 574824702)

$3.99

$

In Stock, only 4 left!

0
