DE 375 (25A-592A100) - Cub Cadet Edger Engine (2001) General Assembly Parts Diagram

Edger Engine

General Assembly Parts Diagram

  • Title

1

Cub Cadet BS-493288

Muffler-Exhaust

$36.99

$

In Stock, Qty 6

0

2

Cub Cadet BS-691720

Muffler/Elbow Locknut

$5.49

$

In Stock, only 1 left!

0

3

Cub Cadet BS-690776

Muffler Adapter

$25.99

$

In Stock, only 1 left!

0

4

Cub Cadet BS-691314

Exhaust Gasket

$6.49

$

In Stock, only 1 left!

0

5

Cub Cadet BS-692336

Screw (Muffler Adapter)

$7.99

$

In Stock, only 2 left!

0

6

Cub Cadet BS-393756

Muffler Deflector

$

$

Not available

7

Cub Cadet BS-690661

Screw (Muffler Deflector)

$3.49

$

In Stock, Qty 20+

0

8

Cub Cadet BS-496914

Armature-Magneto
(Superseded to BS-591420)

$53.99

$

In Stock, Qty 13

0

9

Cub Cadet BS-493880

Sparkplug Terminal
(Superseded to BS-493880S)

$3.49

$

In Stock, Qty 20+

0

10

Cub Cadet BS-691061

Screw (Magneto Armature)

$3.49

$

In Stock, Qty 20+

0

11

Cub Cadet BS-692200

Screw, 3/4" Long (Carburetor)

$

$

Not available

12

Cub Cadet BS-691687

Screw, 1 3/4" Long (Carburetor)

$4.99

$

In Stock, only 1 left!

0

13

Cub Cadet BS-495370

Fuel Tank

$

$

Not available

14

Cub Cadet BS-692241

Fuel Tank Gasket

$4.49

$

In Stock, Qty 20+

0

15

Cub Cadet BS-494559

Fuel Tank Cap

$15.99

$

In Stock, Qty 8

0

16

Cub Cadet BS-691685

Screw (Fuel Tank)

$3.99

$

In Stock, Qty 6

0

17

Cub Cadet BS-692310

Switch-Stop

$5.99

$

In Stock, Qty 20+

0

18

Cub Cadet BS-692904

Choke Link

$9.49

$

Usually ships in 2-12 days

0

19

Cub Cadet BS-692686

Speed Control Panel
(Superseded to BS-692609)

$

$

Not available

20

Cub Cadet BS-692390

Stop Wire

$10.99

$

Usually ships in 2-12 days

0

21

Cub Cadet BS-692200

Screw (Speed Control Panel)

$

$

Not available

22

Cub Cadet BS-690563

Governor Spring

$8.49

$

In Stock, Qty 8

0

23

Cub Cadet BS-691305

Link-Air Vane

$7.49

$

In Stock, Qty 8

0

24

Cub Cadet BS-498770

Governor Blade

$

$

Not available

25

Cub Cadet BS-495605

Engine Gasket Set

$47.99

$

Usually ships in 2-12 days

0

26

Cub Cadet BS-299819

Oil Seal
(Superseded to BS-299819S)

$5.49

$

In Stock, Qty 20+

0

27

Cub Cadet BS-692020

Oil Seal

$10.99

$

In Stock, only 1 left!

0

28

Cub Cadet BS-271935

Air Cleaner Gasket
(Superseded to BS-271935S)

$6.49

$

In Stock, Qty 17

0

29

Cub Cadet BS-692288

Cylinder Head Gasket
(Superseded to BS-698717)

$5.99

$

Usually ships in 2-12 days

0

30

Cub Cadet BS-273113

Intake Gasket
(Superseded to BS-273113S)

$4.49

$

In Stock, Qty 12

0

31

Cub Cadet BS-692189

Grommet

$4.49

$

In Stock, Qty 20+

0

32

Cub Cadet BS-66578

Grommet
(Superseded to BS-692187)

$4.49

$

In Stock, Qty 20+

0

33

Cub Cadet BS-27549

Breather Gasket

$

$

Not available

34

UNKNOWN

$

$

Not available

35

UNKNOWN

$

$

Not available
