EH410D53010 (EH41) - Subaru Robin Engine 302 Intake & Exhaust Parts Diagram

Engine

302 Intake & Exhaust Parts Diagram

  • Title

10

Subaru Robin 267-31701-01

CAMSHAFT CP

$188.11

$

Usually ships in 2-12 days

0

35

Subaru Robin 246-36201-01

RELEASE LEVER CP

Note: End Code: 4473.

$27.99

$

Usually ships in 2-12 days

0

35

Subaru Robin 246-36201-11

RELEASE LEVER CP

Note: Start Code: 4474.

$27.99

$

Usually ships in 2-12 days

0

38

Subaru Robin 246-36701-03

RETURN SPRING

$6.49

$

Usually ships in 2-12 days

0

50

Subaru Robin 239-33301-13

TAPPET

$10.76

$

In Stock, only 2 left!

0

60

Subaru Robin 246-33611-03

VALVE SPRING

$4.99

$

In Stock, only 3 left!

0

70

Subaru Robin 246-33711-03

SPRING RETAINER

$8.99

$

In Stock, only 3 left!

0

80

Subaru Robin 263-33401-03

INTAKE VALVE

$36.99

$

In Stock, only 2 left!

0

90

Subaru Robin 267-33501-03

EXHAUST VALVE

Note: Start Code: 4139.

$72.99

$

In Stock, only 1 left!

0

90

Subaru Robin 263-33501-03

EXHAUST VALVE

Note: End Code: 4138.

$72.99

$

In Stock, only 1 left!

0

95

Subaru Robin 246-35501-03

COLLET-VALVE

$2.49

$

In Stock, Qty 8

0

100

Subaru Robin 023-02200-50

SPACER

Note: Remarks: T=0.6.

$3.49

$

Usually ships in 2-12 days

0

101

Subaru Robin 023-02200-60

SPACER

Note: Remarks: T=0.7.

$3.49

$

Usually ships in 2-12 days

0

102

Subaru Robin 023-02200-70

SPACER

Note: Remarks: T=0.8.

$3.49

$

Usually ships in 2-12 days

0

210

Subaru Robin 267-35301-B1

PUSH ROD CP

Note: Start Code: 4443.

$11.99

$

Usually ships in 2-12 days

0

210

Subaru Robin 267-35301-A1

PUSH ROD CP

Note: End Code: 4442.

$11.99

$

Usually ships in 2-12 days

0

220

Subaru Robin 267-36101-A3

ROCKER ARM

$

$

Not available

230

Subaru Robin 261-35801-13

BOLT(PIVOT)

Note: Start Code: 4657.

$3.49

$

Usually ships in 2-12 days

0

230

Subaru Robin 261-35801-03

BOLT(PIVOT)

Note: End Code: 4656.

$3.49

$

Usually ships in 2-12 days

0

235

Subaru Robin 261-35701-B3

PIVOT

$14.99

$

Usually ships in 2-12 days

0

240

Subaru Robin 017-00601-10

NUT

$1.49

$

In Stock, Qty 10

0

260

Subaru Robin 267-36501-A3

GUIDE PLATE

$6.49

$

Usually ships in 2-12 days

0

340

Subaru Robin 246-35201-03

GASKET(MUFFLER)

$3.49

$

In Stock, only 4 left!

0

350

Subaru Robin 017-00800-30

NUT

$2.49

$

Usually ships in 2-12 days

0

510

267-32607-00

AIR CLEANER AY

$

$

Not available

510

Subaru Robin 234-36003-08

PACKING

$0.99

$

In Stock, Qty 10

0

540

Subaru Robin 267-32901-03

INSULATOR

$9.49

$

Usually ships in 2-12 days

0

550

Subaru Robin 267-35901-A3

GASKET(INSULATOR)

$1.99

$

In Stock, only 3 left!

0

570

Subaru Robin 002-38060-00

FLANGE NUT

$1.99

$

In Stock, Qty 15

0

580

Subaru Robin 001-10061-20

BOLT AND WASHER AY

$1.49

$

Usually ships in 2-12 days

0
