EM5000 A (EM5000) - Honda Generator, Made in Japan (SN: EM5000-1000016 - EM5000-999999) CYLINDER HEAD + COVER Parts Diagram

Generator, Made in Japan

CYLINDER HEAD + COVER Parts Diagram

  • Title

1

Honda 12200-611-040

CYLINDER HEAD

$

$

Not available

2

Honda 12208-634-000

SEE PART DETAILS - PRI; GUIDE, VALVE

$

$

Not available

3

Honda 12205-611-305

GUIDE, EX. VALVE

$

$

Currently unavailable

4

Honda 12209-MB9-003

SEE PART DETAILS - PRI; SEAL, VALVE STEM (NOK)

$15.99

$

Usually ships in 3-6 days

0

4

Honda 12209-300-003

SEE PART DETAILS - SUP; SEAL, VALVE STEM
(Superseded to 12209-MB9-003)

$15.99

$

Usually ships in 3-6 days

0

5

Honda 12251-611-040

SEE PART DETAILS - PRI; GASKET, CYLINDER HEAD

$

$

Not available

6

Honda 12310-611-010

COVER, CYLINDER HEAD

$

$

Not available

7

Honda 12313-862-300

COVER, BREATHER (NOT AVAILABLE)

$

$

Currently unavailable

8

Honda 12314-862-000

GASKET, BREATHER

$

$

Not available

9

Honda 12319-611-000

GASKET, HEAD COVER

$

$

Currently unavailable

10

Honda 15610-611-000

CAP ASSY., OIL FILLER

$

$

Currently unavailable

11

Honda 37765-ZA0-005

SEE PART DETAILS - PRI; SWITCH, THERMOSTAT

$91.99

$

Usually ships in 3-6 days

0

12

Honda 90005-611-003

SEE PART DETAILS - SUP; BOLT, CYLINDER HEAD

$

$

Currently unavailable

12

Honda 90005-611-004

SEE PART DETAILS - PRI; BOLT, CYLINDER HEAD (NOT AVAILABLE)

$

$

Currently unavailable

13

Honda 90006-862-000

BOLT, SEALING (18MM)

$

$

Not available

14

Honda 90013-611-000

BOLT, HEAD COVER

$

$

Not available

15

Honda 90081-611-000

SCREW, TAPPING (6X20)

$

$

Not available

16

Honda 90433-551-000

SEE PART DETAILS - SUP; WASHER (6MM)

$

$

Currently unavailable

17

Honda 90438-611-010

SEE PART DETAILS - SUP; WASHER, SPECIAL (23x11x2.3)

$

$

Not available

18

Honda 90441-611-000

WASHER, HEAD COVER

$

$

Currently unavailable

19

Honda 91203-PG6-003

SEE PART DETAILS - SUP; OIL SEAL (27X43X9) (NOK)
(Superseded to 91203-PFB-013)

$17.99

$

Usually ships in 3-6 days

0

19

Honda 91203-PG6-013

SEE PART DETAILS - SUP; OIL SEAL (27X43X9)
(Superseded to 91203-PFB-013)

$17.99

$

Usually ships in 3-6 days

0

19

Honda 91203-611-004

SEE PART DETAILS - SUP; OIL SEAL (27X43X9) (NOK)

$17.99

$

Usually ships in 3-6 days

0

20

Honda 91307-PH7-660

SEE PART DETAILS - PRI; O-RING (13.5X1.4)

$3.99

$

In Stock, only 2 left!

0

21

Honda 91307-PH9-000

SEE PART DETAILS - PRI; O-RING (15.5X1.4)

$

$

Not available

22

Honda 92101-06012-0H

SEE PART DETAILS - PRI; BOLT, HEX. (6X20)

$1.99

$

Usually ships in 3-6 days

0

23

Honda 92700-08040-0B

SEE PART DETAILS - PRI; BOLT, STUD (8X40)

$2.99

$

Usually ships in 3-6 days

0

24

Honda 94021-06020

SEE PART DETAILS - PRI; NUT, CAP (6MM)

$2.49

$

Usually ships in 3-6 days

0

25

Honda 98079-56840

SEE PART DETAILS - PRI; SPARK PLUG (B6E) (NGK)

$3.99

$

Usually ships in 3-6 days

0
