EV4000 A (EV4000) - Honda Generator, Made in Japan (SN: EV4000-1000001 - EV4000-9999999) CYLINDER + CYLINDER HEAD Parts Diagram

Generator, Made in Japan

CYLINDER + CYLINDER HEAD Parts Diagram

  • Title

1

Honda 11210-822-010

COVER, OIL PAN

$3.99

$

Usually ships in 3-6 days

0

2

Honda 121A0-890-040

CYLINDER (CRANKSHAFT P.T.O.)

Note: Use from Engine SN 1350780.

$

$

Not available

2

Honda 12100-890-335

CYLINDER (CRANKSHAFT P.T.O.) (NOT AVAILABLE)

Note: Use up to Engine SN 1350779.

$

$

Currently unavailable

3

Honda 12134-890-305

GUIDE, VALVE

$8.99

$

Usually ships in 3-6 days

0

4

Honda 12221-890-731

CYLINDER HEAD (NOT AVAILABLE)

$

$

Not available

5

Honda 12281-890-306

SEE PART DETAILS - SUP; GASKET, CYLINDER HEAD

$33.99

$

Usually ships in 3-6 days

0

5

Honda 12281-891-610

SEE PART DETAILS - PRI; GASKET, CYLINDER HEAD

$

$

Not available

6

Honda 12360-890-000

CASE, BREATHER

$15.99

$

Usually ships in 3-6 days

0

7

Honda 12361-890-000

COVER, TAPPET

$9.49

$

Usually ships in 3-6 days

0

8

Honda 12367-890-003

FILTER, BREATHER

$

$

Not available

9

Honda 12369-883-000

SEAL, BREATHER

$3.99

$

Usually ships in 3-6 days

0

10

Honda 12375-ZA1-000

GASKET, TAPPET COVER

$2.99

$

Usually ships in 3-6 days

0

11

Honda 16279-880-000

COVER, THERMOSTAT SWITCH

$

$

Not available

12

Honda 16500-880-023

SWITCH ASSY., THERMOSTAT (NOT AVAILABLE)

$

$

Not available

13

Honda 16501-880-000

BOSS, THERMOSTAT SWITCH (NOT AVAILABLE)

$

$

Currently unavailable

14

Honda 16502-880-000

WASHER, SWITCH BOSS

$1.99

$

Usually ships in 3-6 days

0

15

Honda 18311-890-670

PIPE, EX.

$

$

Currently unavailable

16

Honda 18381-890-306

SEE PART DETAILS - SUP; GASKET, MUFFLER
(Superseded to 18381-890-800)

$

$

Not available

16

Honda 18381-890-800

SEE PART DETAILS - PRI; GASKET, MUFFLER

$

$

Not available

17

Honda 80102-323-000

GROMMET, CABLE

$

$

Not available

18

Honda 90042-890-010

BOLT, STUD (8X110)

Note: Use from Engine SN 1302193.

$7.99

$

Usually ships in 3-6 days

0

18

Honda 90042-890-680

BOLT, STUD (8X104)

Note: Use up to Engine SN 1302192.

$7.99

$

Usually ships in 3-6 days

0

19

Honda 90047-883-000

BOLT, STUD (8X35)

$4.49

$

Usually ships in 3-6 days

0

20

Honda 90131-896-650

SEE PART DETAILS - PRI; BOLT, DRAIN PLUG

$4.99

$

In Stock, Qty 11

0

21

Honda 91201-890-003

OIL SEAL (30X46X8)

$10.99

$

In Stock, Qty 7

0

22

Honda 91301-028-000

O-RING (27X2.0)

$3.99

$

Usually ships in 3-6 days

0

23

Honda 90045-890-000

BOLT, STUD (10X70)

Note: Use from Engine SN 1297698.

$7.49

$

Usually ships in 3-6 days

0

23

Honda 92700-10060-0B

SEE PART DETAILS - SUP; BOLT, STUD (10X60)

Note: Use from Engine SN 1269742 to 1297697.

$

$

Currently unavailable

23

Honda 92900-10040-0B

SEE PART DETAILS - PRI; BOLT, STUD (10X40)

Note: Use from Engine SN 1269742 to 1297697.

$10.99

$

Usually ships in 3-6 days

0

24

Honda 93412-06012-08

SEE PART DETAILS - SUP; BOLT-WASHER (6X12)

$

$

Currently unavailable

25

Honda 94050-08000

SEE PART DETAILS - PRI; NUT, FLANGE (8MM)

$1.49

$

In Stock, Qty 20+

0

26

Honda 94050-10000

SEE PART DETAILS - PRI; NUT, FLANGE (10MM)

Note: Use from Engine SN 1269742 to 1297697.

$1.99

$

In Stock, Qty 5

0

26

Honda 94050-10080

NUT, FLANGE (10MM)

Note: Use from Engine SN 1297698.

$3.99

$

In Stock, Qty 20+

0

27

Honda 90401-437-000

WASHER, PLAIN (10MM)

Note: Use from Engine SN 1297698.

$3.49

$

Usually ships in 3-6 days

0

27

Honda 94102-10000

WASHER, PLAIN (10MM)

Note: Use from Engine SN 1269742 to 1297697.

$0.99

$

In Stock, only 2 left!

0

28

Honda 94109-12000

WASHER, DRAIN PLUG (12MM)

$1.49

$

In Stock, Qty 20+

0

29

Honda 94301-08140

PIN A, DOWEL (8X14)

$2.99

$

In Stock, Qty 14

0

30

Honda 95700-06012-08

SEE PART DETAILS - SUP; BOLT, FLANGE (6X12)

$

$

Currently unavailable

30

Honda 95701-06012-08

SEE PART DETAILS - PRI; BOLT, FLANGE (6X12)

$2.49

$

In Stock, only 2 left!

0

31

Honda 95701-08016-08

BOLT, FLANGE (8X16)

$2.49

$

In Stock, Qty 6

0

32

Honda 95730-10055-08

BOLT, FLANGE (10X55)

Note: Use up to Engine SN 1269741.

$2.49

$

Usually ships in 3-6 days

0

32

Honda 95730-10055-08

BOLT, FLANGE (10X55)

Note: Use from Engine SN 1269742.

$2.49

$

Usually ships in 3-6 days

0

33

Honda 98076-56917

SPARK PLUG (BPR6HS-10) (NGK)

$3.49

$

In Stock, Qty 20+

0

33

Honda 98076-56927

SEE PART DETAILS - PRI; SPARK PLUG (W20FPR-U10)

$3.99

$

Usually ships in 3-6 days

0
