F 160Z (5901516) - Ferris F160Z Series 48" Zero-Turn Mower, 26hp Briggs & Stratton Seat Mount and Floor Group S/N: 2017724860 and Below Parts Diagram

F160Z Series 48" Zero-Turn Mower, 26hp Briggs & Stratton

Seat Mount and Floor Group S/N: 2017724860 and Below Parts Diagram

  • Title

1

Ferris 5025392

NUT, 5/16-18 HEX NYLOCK FLANGE
(Superseded to 5025392FS)

$3.49

$

Usually ships in 2-12 days

0

2

Ferris 5044617

WASHER, .34 X 1.25 X 10 GA
(Superseded to 5044617SM)

$8.49

$

Usually ships in 2-12 days

0

3

Ferris 5025011X18

BOLT, 5/16-18 X 2-1/4 GD5 YZ
(Superseded to 5025011X18SM)

$4.49

$

Usually ships in 2-12 days

0

4

Ferris 5025155

WASHER, 5/16" SAE

$

$

Currently unavailable

5

Ferris 5025011X8

BOLT, 5/16-18 X 1 GD5 YZ
(Superseded to 5025011X8FS)

$3.99

$

In Stock, Qty 14

0

6

Ferris 5025156

WASHER, 3/8 SAE
(Superseded to 5025156FS)

$3.49

$

Usually ships in 2-12 days

0

7

Ferris 5025013X32

BOLT, 3/8-16 X 4" GD5 CZ
(Superseded to 5025013X32SM)

$4.49

$

In Stock, Qty 9

0

8

Ferris 5025394

NUT, 3/8-16 HEX NYLOCK FLANGE
(Superseded to 5025394SM)

$4.49

$

In Stock, Qty 20+

0

9

Ferris 5025145X6

BOLT, 5/16-18 X 3/4, CARRIAGE
(Superseded to 5025145X6SM)

$3.99

$

In Stock, Qty 20+

0

10

Ferris 5025145X10

BOLT, 5/16-18 X 1-1/4, CARRIAGE YZ
(Superseded to 5025145X10YP)

$3.49

$

In Stock, only 2 left!

0

11

Ferris 80003675

NUT, 5/16-18, HEX, CNTR LK,ZINC PHOS/OIL
(Superseded to 703164)

$3.49

$

In Stock, Qty 20+

0

12

Ferris 1670578

KNOB-INT THR .312-18 4-ARM 2.12WD 1.06LG
(Superseded to 1670578SM)

$14.99

$

In Stock, only 4 left!

0

13

Ferris 5101374

SAFETY WALK, FLOOR REST, 6.00 X 16.00
(Superseded to 5101374YP)

$19.99

$

In Stock, only 2 left!

0

14

Ferris 5101333

SAFETY WALK, FLOOR PLATE, S50X, 10X16
(Superseded to 5101333YP)

$39.99

$

In Stock, only 1 left!

0

15

Ferris 7078299

SPRING, SEAT SUPPORT
(Superseded to 7078299SM)

$15.99

$

In Stock, only 4 left!

0

16

Ferris 5102211

SPRING, COMP 720ID X 1.310LG X .118WIRE
(Superseded to 5102211YP)

$33.99

$

Usually ships in 2-12 days

0

17

Ferris 5402732B

PLATE, SEAT SWITCH - RED

$13.99

$

Usually ships in 2-12 days

0

18

Ferris 5102228

SPACER, .33 X .66 X 1.31 SHLDR, CZ
(Superseded to 5102228YP)

$15.99

$

Usually ships in 2-12 days

0

19

Ferris 197546

MNT, VBRTN, RBBR
(Superseded to 197546GS)

$8.49

$

In Stock, Qty 5

0

20

Ferris 5600919

ASSM, SEAT PLATE W/DECALS, F160Z-DOM (5413405B)

$367.99

$

Usually ships in 2-12 days

0

21

Ferris 5410774B

PLATE, FLOOR, NON REMOVABLE - RED
(Superseded to 5410774BFS)

$68.99

$

Usually ships in 2-12 days

0

22

Ferris 5410296B

PLATE, FLOOR, REMOVABLE, IS700 - RED
(Superseded to 5410296BFS)

$86.99

$

Usually ships in 2-12 days

0

23

Ferris 5104720

SEAT, MID BACK W/SUSPENSION, SEATS INC
(Superseded to 5105096)

$

$

Not available

23-1

Ferris 5104720X1

4" SINGLE LOCKING TRACKS BASE

Note: (SV)

$148.99

$

Usually ships in 2-12 days

0

23-2

Ferris 5104719X1

ARM PAD ASSEMBLY BLK/CHAR CAR FIB/HARBR GRY RED WELT
(Superseded to 5104681X4)

Note: (SV)

$91.99

$

Usually ships in 2-12 days

0

23-3

Ferris 5104719X2

SET OF ARMREST ASSEMBLY BLK/CHAR CAR FIB/HARBR GRY RED WELT

Note: (SV)

$403.99

$

Usually ships in 2-12 days

0

23-4

Ferris 5104720X2

WEIGHT ADJUST INDICATOR KNOB ASSY BASE

Note: (SV)

$85.99

$

Usually ships in 2-12 days

0

23-5

Ferris 5104720X3

BELLOWS W/ HARDWARE BASE

Note: (SV)

$100.99

$

Usually ships in 2-12 days

0

23-6

Ferris 5104720X4

BACK COVER FOR FIXED BACK I3M BLK/CHAR CAR FIB/HARBR GRY RED WELT

Note: (SV)

$240.99

$

Usually ships in 2-12 days

0

23-7

Ferris 5104720X5

CUSHION COVER FOR I3M BLK/CHAR CAR FIB/HARBR GRY RED WELT

Note: (SV)

$210.99

$

Usually ships in 2-12 days

0
