Flail Mower - BCS America BladeRunner Flail Mower Attachment Flail Rotor (SN: 380128 & Above) Parts Diagram

BladeRunner Flail Mower Attachment

Flail Rotor (SN: 380128 & Above) Parts Diagram

  • Title

1

BCS America 311.22803

CAPSCREW M8X25

Note:

$1.49

$

Usually ships in 5-8 days

0

2

BCS America 312.41084

NUT

Note:

$1.49

$

Usually ships in 5-8 days

0

3

BCS America 312.41121

LOCKNUT M12, LOW PROFILE

Note:

$1.49

$

Usually ships in 5-8 days

0

4A

BCS America 314.00220

SHIM 50X62/0.2

Note:

$1.99

$

Usually ships in 5-8 days

0

4B

BCS America 314.00222

SHIM 50X62/1.5

Note:

$5.49

$

Usually ships in 5-8 days

0

4C

BCS America 314.00223

SHIM 50X62/0.5

Note:

$1.99

$

Usually ships in 5-8 days

0

5

BCS America 314.11130

WASHER FLAT M13X24

Note:

$0.99

$

Usually ships in 5-8 days

0

6

BCS America 351.11062

SNAP RING INTERNAL D 62

Note:

$2.49

$

Usually ships in 5-8 days

0

7

BCS America 371.12298

BEARING

Note:

$124.99

$

Usually ships in 5-8 days

0

8

BCS America 561.58382N

CAP

Note:

$

$

Currently unavailable

9

BCS America 561.93937

GUARD

Note:

$18.99

$

Usually ships in 5-8 days

0

10

BCS America 561.94016

SPACER

Note:

$2.49

$

Usually ships in 5-8 days

0

11

BCS America 580.58359

SCREW

Note:

$8.99

$

Usually ships in 5-8 days

0

12

BCS America 581.59950

CUP KNIFE (OPTIONAL)

Note:

$18.99

$

Usually ships in 5-8 days

0

13

BCS America 581.59952

STRAIGHT KNIFE (OPTIONAL)

Note:

$15.99

$

Usually ships in 5-8 days

0

14

BCS America 581.93581

KNIFE, FLAIL MOWER

Note:

$8.49

$

In Stock, Qty 5

0

15A

BCS America 590.59318

ROLLER AXLE 24IN

Note:

$

$

Not available

15B

BCS America 590.59320

ROLLER AXLE 30IN

Note:

$

$

Not available

16

BCS America 590.59949

FLANGE

Note:

$

$

Not available

17

BCS America 592.59456

KIT, COMP. 30" LAWN MOWING

Note:

$221.56

$

Usually ships in 5-8 days

0

17

BCS America 592.59457

KIT, COMP. 26" LAWN MOWING

Note:

$

$

Currently unavailable
