FR-1800 (131-013-190) - White Outdoor Front-Mount Riding Mower (1991)

Front-Mount Riding Mower

FR-1800 (131-013-190) - White Outdoor Front-Mount Riding Mower (1991) > Parts Diagrams (25) > Agri-Fab Sundstrand Base Assembly

  • Title
WD-114-0000

Bage, SA 0

Part# WD-114-0000

OEM Warranty Repair Part for White Outdoor

Not available

WD-301-0024

2

Deck Arm

Part# WD-301-0024

Not available

WD-300-0023L.H.

3

Deck Arm, Front, LH

Part# WD-300-0023L.H.

Not available

WD-300-0023R.H.

4

Deck Arm, Front, RH

Part# WD-300-0023R.H.

Not available

WD-300-0022

5

Cross Bar Pin

Part# WD-300-0022

Not available

WD-300-0014

6

Cross Bar

Part# WD-300-0014

OEM Warranty Repair Part for White Outdoor

Not available

WD-300-0041

7

Wire Tube

Part# WD-300-0041

OEM Warranty Repair Part for White Outdoor

Not available

WD-111-0023

8

Forward Nose Down Lock

Part# WD-111-0023

OEM Warranty Repair Part for White Outdoor

Not available

WD-114-0003

9

Drive Idler Tube

Part# WD-114-0003

OEM Warranty Repair Part for White Outdoor

Not available

WD-300-0013

10

Deck Llft Arm Bushlng, Short

Part# WD-300-0013 (Superseded to WD-C37586)

OEM Warranty Repair Part for White Outdoor

Not available

WD-300-0013

11

Deck Llft Aro Bushing

Part# WD-300-0013 (Superseded to WD-C37586)

OEM Warranty Repair Part for White Outdoor

Not available

WD-900-6129

12

Hex Bolt, 112-13 x 1 1/4", GRS

Part# WD-900-6129

Not available

WD-900-6131

13

Hex Bolt, 1/2-13 x 2 1/4", GRS

Part# WD-900-6131

Not available

WD-900-6088

14

Hex Tap Bolt, 3/8-16 0 3", GRS

Part# WD-900-6088

OEM Warranty Repair Part for White Outdoor

Not available

WD-900-6128

15

Flatwaher, 1/2"

Part# WD-900-6128

Not available

WD-900-6127

16

Lockw cher, 1/2"

Part# WD-900-6127 (Superseded to 936-0921)

OEM Warranty Repair Part for White Outdoor

Usually leaves our warehouse in 5 to 10 business days

Your price: $3.11

WD-900-6067

17

Lockwasher, 3/8"

Part# WD-900-6067

Not available

WD-900-6075

18

Hex Nut, 3/8-16

Part# WD-900-6075

Not available

WD-900-6125

19

Hex Nut, 1/2-11

Part# WD-900-6125 (Superseded to 912-0206)

OEM Warranty Repair Part for White Outdoor

Usually leaves our warehouse in 5 to 10 business days

Your price: $3.11

WD-900-6176

20

Cotter Pin, 1/8" x 1"

Part# WD-900-6176

Not available

WD-900-5580

21

Trans Belt Tightener Spring

Part# WD-900-5580

OEM Warranty Repair Part for White Outdoor

Not available

WD-900-2553

22

Idler Pulley, 2 1/4" OD

Part# WD-900-2553

OEM Warranty Repair Part for White Outdoor

Not available

WD-900-6027

23

Elastlc Stop Nut, 1/4-20

Part# WD-900-6027

Not available

WD-114-0014

24

L Brake Linkage

Part# WD-114-0014

Not available

WD-900-6031

25

Hex Bolt, 1/4-20 x 1", GRS

Part# WD-900-6031

Not available

WD-900-5824

26

Clutch Brak-Cable

Part# WD-900-5824

Not available

WD-111-0014

27

Caliper Rod Collar

Part# WD-111-0014

OEM Warranty Repair Part for White Outdoor

Not available

WD-111-0007

28

Caliper Rod

Part# WD-111-0007

OEM Warranty Repair Part for White Outdoor

Not available

WD-900-6175

29

Cotter Pin, 3/32" x 1"

Part# WD-900-6175

Not available

WD-900-2554

30

Cable Pulley, 1 1/2" OD

Part# WD-900-2554

Not available

WD-114-0010

31

Engine Retainer Bracket

Part# WD-114-0010

Not available

WD-114-0011

32

Englne Belt Retainer

Part# WD-114-0011

OEM Warranty Repair Part for White Outdoor

Not available

WD-301-0024L.H.

33

Deck Arm, LH

Part# WD-301-0024L.H.

Not available
