FR-1800 (131-013-190) - White Outdoor Front-Mount Riding Mower (1991)

Front-Mount Riding Mower

FR-1800 (131-013-190) - White Outdoor Front-Mount Riding Mower (1991) > Parts Diagrams (25) > Agri-Fab Sundstrand Drive Assembly Right Hand Drive Parts

  • Title
WD-900-8134

1

ZT Transmission

Part# WD-900-8134

OEM Warranty Repair Part for White Outdoor

Not available

WD-900-7050

2

Brake Band

Part# WD-900-7050

OEM Warranty Repair Part for White Outdoor

Not available

WD-900-7051

3

Brake Drum

Part# WD-900-7051

OEM Warranty Repair Part for White Outdoor

Not available

WD-900-7052

4

Snap Rlng

Part# WD-900-7052

OEM Warranty Repair Part for White Outdoor

Not available

WD-900-6167

5

Coteer Pin, 1/8" x 1"

Part# WD-900-6167

Not available

WD-114-0004

6

Brake Linkage Rod

Part# WD-114-0004

OEM Warranty Repair Part for White Outdoor

Not available

WD-111-0014

7

Caliper Rod Collar

Part# WD-111-0014

OEM Warranty Repair Part for White Outdoor

Not available

WD-900-6027

8

Elastlc Stop Nut, 1/4-20

Part# WD-900-6027

Not available

WD-900-5722

9

Spring

Part# WD-900-5722

OEM Warranty Repair Part for White Outdoor

Not available

WD-900-6029

10

Flatwasher, 1/4"

Part# WD-900-6029

Not available

WD-900-7045

11

Spacer

Part# WD-900-7045

OEM Warranty Repair Part for White Outdoor

Not available

WD-900-7046

12

Snap Ring

Part# WD-900-7046 (Superseded to 716-0865)

OEM Warranty Repair Part for White Outdoor

Usually leaves our warehouse in 1 business day

Your price: $3.10

WD-900-7047

13

Gear

Part# WD-900-7047

OEM Warranty Repair Part for White Outdoor

Not available

WD-900-7048

14

Bearing

Part# WD-900-7048 (Superseded to 941-0155)

OEM Warranty Repair Part for White Outdoor

Usually leaves our warehouse in 1 business day

Your price: $17.54

WD-900-7049

15

Spacer

Part# WD-900-7049

OEM Warranty Repair Part for White Outdoor

Not available

WD-900-8132

17

Sundstrand Pump, RH

Part# WD-900-8132

OEM Warranty Repair Part for White Outdoor

Not available

WD-114-0005

18

Transmission Dump Lever

Part# WD-114-0005

OEM Warranty Repair Part for White Outdoor

Not available

WD-114-0001

19

Transmission Dump Lever Stop

Part# WD-114-0001

Not available

WD-900-6501

20

Compression Spring, 9/16" OD x 1 3/8"

Part# WD-900-6501

OEM Warranty Repair Part for White Outdoor

Not available

WD-900-6052

21

Flatwasher, 3/8"

Part# WD-900-6052

Not available

WD-114-0013

22

Transmission Arm

Part# WD-114-0013

Not available

WD-900-6019

23

Dump Valve Bolt

Part# WD-900-6019

Not available

WD-900-6051

24

Lockwasher, 5/16"

Part# WD-900-6051

Not available

WD-900-6050

25

Hex Nut, 5/16-18

Part# WD-900-6050

Not available

WD-900-6061

27

Hex Bolt, 5/16-18 x 2", GRS

Part# WD-900-6061

Not available

WD-900-6073

28

Hex Bolt, 5/16-18 x 7 1/2", GRS

Part# WD-900-6073 (Superseded to 710-0157)

OEM Warranty Repair Part for White Outdoor

Usually leaves our warehouse in 1 business day

Your price: $3.09

WD-900-5840

29

Lockwasher, 3/8"

Part# WD-900-5840

Not available

WD-900-8164

30

Hex Nut, 3/8-16

Part# WD-900-8164

OEM Warranty Repair Part for White Outdoor

Not available

WD-900-6168

31

Key, 5 x 5 x 25mm

Part# WD-900-6168

OEM Warranty Repair Part for White Outdoor

Not available

WD-900-2552

32

Pulley, 4" OD x l5mn ID

Part# WD-900-2552

OEM Warranty Repair Part for White Outdoor

Not available

WD-900-8168

33

Male Tube, Male O-ring Adapter

Part# WD-900-8168

OEM Warranty Repair Part for White Outdoor

Not available

WD-900-8116

34

Male Tube, 90ø Male O-ring Adpt.

Part# WD-900-8116

OEM Warranty Repair Part for White Outdoor

Not available

WD-900-6058

35

Squarehead Setscrew, 5/16-L8 x 1/2"

Part# WD-900-6058

Not available

WD-900-6058

36

Lockwasher, 1/4"

Part# WD-900-6058

Not available

WD-900-6028

37

Hex Nue, 1/4-20

Part# WD-900-6028

Not available

WD-900-5503

38

Steering Cable Clamp

Part# WD-900-5503 (Superseded to WD-C37616)

OEM Warranty Repair Part for White Outdoor

Not available

WD-200-0014

39

Steering Cable Bushing

Part# WD-200-0014 (Superseded to WD-C42895)

OEM Warranty Repair Part for White Outdoor

Not available

WD-900-6031

40

Hex Bolt, 1/4-20 x 1", GRS

Part# WD-900-6031

Not available

WD-200-0013

41

Steerlng Cable Ent

Part# WD-200-0013 (Superseded to WD-C37614)

OEM Warranty Repair Part for White Outdoor

Not available

WD-900-6150

42

Hex Nut w/Star Washer, 10-32

Part# WD-900-6150

OEM Warranty Repair Part for White Outdoor

Not available

WD-900-5819

43

Steerlng Cable, 3/16" x 58"

Part# WD-900-5819

OEM Warranty Repair Part for White Outdoor

Not available

WD-900-3027

44

Pump Drlve Belt

Part# WD-900-3027

OEM Warranty Repair Part for White Outdoor

Not available

WD-900-3010

45

Belt

Part# WD-900-3010 (Superseded to WD-C37762)

OEM Warranty Repair Part for White Outdoor

Not available

WD-900-4048

69

Drive Wheel Assembly

Part# WD-900-4048

OEM Warranty Repair Part for White Outdoor

Not available

WD-900-4042

Tire, 18 x 9.50

Part# WD-900-4042

OEM Warranty Repair Part for White Outdoor

Not available

WD-900-4040

Rim, 8 x 5 1/2"

Part# WD-900-4040

OEM Warranty Repair Part for White Outdoor

Not available

WD-900-6138

70

Lug Nut, 1/2-20

Part# WD-900-6138

OEM Warranty Repair Part for White Outdoor

Not available
