FR-1800 D (135-028-190) - White Outdoor Front-Mount Riding Mower (1995) Parking Brake Parts Diagram

Front-Mount Riding Mower

Parking Brake Parts Diagram

  • Title

1

WD-C45370

LEVER - brake

$

$

Not available

2

White Outdoor WD-C37631

GRIP - handle

$

$

Not available

3

WD-C45387

STOP - lever

$

$

Not available

4

White Outdoor WD-113-3

BOLT - 1/4" - 20 x 3/4"

$

$

Not available

5

WD-192-19

LOCKWASHER - 1 /4"

$

$

Not available

6

WD-129-101

NUT - 1/4" - 20

$

$

Not available

7

WD-C45432

ARM - actuator

$

$

Not available

8

WD-C45375

ROD - brake

$

$

Not available

9

WD-132-310

PIN - cotter 1/8" x 1"

$

$

Not available

10

White Outdoor WD-111-111

BOLT - 1/4" - 20 x 1" carriage

$

$

Not available

11

WD-C45324

SHAFT - cross

$

$

Not available

12

WD-187-1036

BOLT - 1 /4" - 20 x 1/2" flange

$

$

Not available

13

White Outdoor WD-131-934

NUT - 1/4" - 20 flange lock

$

$

Not available

14

WD-C45503

BAR - brake link

$

$

Not available

15

WD-195-525

WASHER - .40" x .81"

$

$

Not available

16

WD-132-321

PIN - cotter 1/8" - 1"

$

$

Not available

17

White Outdoor WD-C42896

BUSHING

$

$

Not available

18

WD-113-4

BOLT - 1/4" - 20 x 1"

$

$

Not available

19

White Outdoor WD-195-102

WASHER - .31" x .75"

$

$

Not available

20

White Outdoor WD-131-71

NUT - 1/4" - 20 lock

$

$

Not available

21

WD-113-118

BOLT - 5/16" - 18 x 5/8"

$

$

Not available

22

White Outdoor WD-131-911

NUT - 5/16" - 18 flange lock
(Superseded to 712-3004A)

$3.49

$

In Stock, Qty 20+

0

23

WD-C45501

CLEVIS - brake

$

$

Not available

24

White Outdoor WD-131-938

NUT - 3/8" - 18 flange lock

$

$

Not available
