FZ 1300 H - Billy Goat Z-Force Blower for Zero-Turn Mowers Parts Assembly Parts Diagram

Z-Force Blower for Zero-Turn Mowers

Parts Assembly Parts Diagram

  • Title

1

Billy Goat 442501

LABEL LOGO FZ

$

$

Not available

2

Billy Goat 442500

LABEL WARNING FZ

$

$

Not available

3

Billy Goat 442600

FRAME WA FZ W/LABELS

$

$

Not available

4

Billy Goat 442203

JRCO BRACKET

$123.99

$

In Stock, only 2 left!

0

5

Billy Goat 440018

ENGINE 13 HP HONDA

$

$

Not available

6

Billy Goat 442601

HOUSING WA FZ W/LABELS

$

$

Not available

7

Billy Goat 442602

IMPELLER ASSY FZ

$393.99

$

Usually ships in 2-11 days

0

8

Billy Goat 8177012

WASHER LOCK 3/8" S/T MED

$0.99

$

In Stock, Qty 7

0

9

Billy Goat 8177010

WASHER LOCK 1/4" S/T MED

$

$

Not available

10

Billy Goat 8041057

SCREWCAP 3/8"-16 X 2 3/4" HCS ZP

$1.49

$

Usually ships in 2-11 days

0

11

Billy Goat 8041050

SCREWCAP 3/8"-16 X 1" HCS ZP

$0.99

$

In Stock, Qty 5

0

12

Billy Goat 442237

SCREWCAP 3/8"-24 X 3 1/4" GR. 8 HCS

$

$

Not available

13

Billy Goat 442236

SCREWCAP 1/4"-28 X 3/4"

$

$

Not available

14

Billy Goat 8041031

SCREWCAP 5/16" - 18 X 1 3/4" HCS ZP

$0.99

$

In Stock, only 3 left!

0

15

Billy Goat 442506

LABEL GAS SHUT OFF

$

$

Not available

16

Billy Goat 360187

LABEL LIFT HERE

$3.99

$

Usually ships in 2-11 days

0

17

Billy Goat 442605

ELBOW EXHAUST ASSY

$

$

Not available

18

Billy Goat 810736

LABEL WARNING DEBRIS

$3.99

$

Usually ships in 2-11 days

0

19

Billy Goat 440178

CABLE THROTTLE 31.5

$32.99

$

Usually ships in 2-11 days

0

20

Billy Goat 900407

TY-WRAP

$0.99

$

Usually ships in 2-11 days

0

21

Billy Goat 442603

PLATE FRONT WA FZ W/LABEL

$

$

Not available

22

Billy Goat 442202

PIN HITCH 5/8" X 4 1/2"

$

$

Not available

23

Billy Goat 442231

SPACER CRANK FZ13H

$

$

Not available

24

Billy Goat 442247

WHEEL 12" W/3/4" BEARING

$212.99

$

Usually ships in 2-11 days

0

25

Billy Goat 442205

MOTOR 12V

$449.99

$

Usually ships in 2-11 days

0

26

Billy Goat 442240

PULLEY 1.63" OD X 7/16" BORE

$49.99

$

In Stock, only 1 left!

0

27

Billy Goat 8083122

SET SCREW 1/4" - 20 X .375 CUP POINT

$5.99

$

Usually ships in 2-11 days

0

28

Billy Goat 442400

THROTTLE STEM

$

$

Not available

29

Billy Goat 500385

THROTTLE PLATE

$13.99

$

Usually ships in 2-11 days

0

30

Billy Goat 440013

CONTROL THROTTLE

$41.99

$

In Stock, Qty 8

0

31

Billy Goat 510130

PIN 3/8" X 1 1/2" DETENT

$41.99

$

Usually ships in 2-11 days

0

32

Billy Goat 360284

BOLT SHOULDER 3/8" X 1"

$3.99

$

In Stock, only 1 left!

0

33

Billy Goat 8160003

NUT LOCK 3/8"-16

$0.99

$

In Stock, Qty 14

0

34

Billy Goat 8171003

WASHER 5/16" FC

$0.99

$

In Stock, Qty 16

0

35

Billy Goat 8171002

WASHER 1/4" FC

$0.99

$

In Stock, Qty 6

0

36

Billy Goat 8171008

WASHER 3/4" FC

$0.99

$

Usually ships in 2-11 days

0

37

Billy Goat 8171004

WASHER 3/8" FC

$0.99

$

In Stock, only 3 left!

0

38

Billy Goat 440176

WASHER 1.5 OD X .453 ID X .5 THK

$2.99

$

In Stock, only 4 left!

0

39

Billy Goat 8041007

SCREWCAP 1/4"-20 X 1 1/4" HCS MED

$0.99

$

Usually ships in 2-11 days

0

40

Billy Goat 8160002

NUT LOCK 5/16" - 18 HEX ZP

$0.99

$

In Stock, Qty 11

0

41

Billy Goat 442243

CAP INDICATOR RED

$

$

Not available

42

Billy Goat 442200

CASTER RIG 12"

$

$

Not available

43

Billy Goat 8041051

SCREWCAP 3/8 - 16 X 1 1/4" HCS ZP

$0.99

$

In Stock, Qty 7

0

44

Billy Goat 440268

LABEL LOGO FORCE

$6.99

$

Usually ships in 2-11 days

0

45

Billy Goat 442604

SWITCH BOX TOP PLATE W/TREAD TAPE

$

$

Not available

46

Billy Goat 8161041

NUT LOCK 5/16" TH HT HEX ZP

$0.99

$

In Stock, Qty 13

0

47

Billy Goat 830514

SCREW MACH #10-24 X 1/2"

$0.99

$

Usually ships in 2-11 days

0

48

Billy Goat 8164005

NUT LOCK #10 - 32

$0.99

$

In Stock, only 1 left!

0

49

Billy Goat 350346

NUT FLANGE 5/16" - 18 ZP

$0.99

$

In Stock, only 1 left!

0

50

Billy Goat 8160001

NUT LOCK 1/4 - 20

$0.99

$

In Stock, only 2 left!

0

51

Billy Goat 8041175

SCREWCAP 3/4 - 10 X 5 1/2"

$8.99

$

Usually ships in 2-11 days

0

52

Billy Goat 8161006

NUT LOCK 3/4"-10 ZP

$1.99

$

Usually ships in 2-11 days

0

53

Billy Goat 442213

HARNESS WIRE FZ BATTERY

$

$

Not available

54

Billy Goat 442214

HARNESS WIRE ROTATOR SWITCH

$

$

Not available

55

Billy Goat 360243

LANYARD PLASTIC 10"

$5.49

$

Usually ships in 2-11 days

0

56

Billy Goat 442215

HARNESS WIRE CONTROL

$

$

Not available

57

Billy Goat 890132

PLUG TUBE INSERT 1" OD

$

$

Not available

58

Billy Goat 442204

SCREW BUTTON HEAD 5/16-18 X 1 1/4"

$

$

Not available

59

Billy Goat 500282

STRAIN RELIEF

$2.99

$

In Stock, only 2 left!

0

60

Billy Goat 9201123

KEY 1/4" SQ X 2.25"

$

$

Not available

61

Billy Goat 442103

SWITCH BOX WA

$

$

Not available

62

Billy Goat 442401

TUBE KICK STAND

$

$

Not available

63

Billy Goat 442241

STAND OFF NOZZLE FZ

$

$

Not available

64

Billy Goat 520116

LABEL MADE IN USA

$

$

Not available

65

Billy Goat 442105

STAND OFF ENGINE FZ WA

$

$

Not available

66

Billy Goat 500119

BELT GATES TRUFLEX 1260

$46.99

$

In Stock, only 1 left!

0

67

Billy Goat 8041028

SCREWCAP 5/16" - 18 X 1 1/4" HEX ZP

$0.99

$

In Stock, Qty 11

0

68

Billy Goat 442106

INDICATOR DIRECTION WA

$

$

Not available

69

Billy Goat 442216

SPRING .578 OD X 3.16 LONG

$

$

Not available

70

Billy Goat 791095

SWITCH ROTATOR

$50.99

$

Usually ships in 2-11 days

0

71

Billy Goat 8041041

SCREWCAP 5/16 -18 X 4 1/2"

$1.49

$

Usually ships in 2-11 days

0

72

Billy Goat 810656

LABEL THROTTLE CONTROL

$3.99

$

Usually ships in 2-11 days

0
