G1 - Husqvarna Automower Robotic Lawn Mower (1998-2003) INSTALLATION ACCESSORIES Parts Diagram

Automower Robotic Lawn Mower

INSTALLATION ACCESSORIES Parts Diagram

  • Title

535 04 16-01

Husqvarna 535041601

CABLE/750 FEET

$

$

Not available

535 09 85-01

Husqvarna 535098501

PLASTIC CARD, KIT

$

$

Not available

535 08 79-01

Husqvarna 535087901

GROUND MESH, CHARGER
(Superseded to 535103001)

$

$

Not available

535 07 85-01

Husqvarna 535078501

TRANSFORMER

Note: EU

$

$

Not available

535 07 88-01

Husqvarna 535078801

120 VOLT TRANSFORMER

Note: US

$

$

Not available

535 07 89-01

Husqvarna 535078901

POWER CABLE CHG

$

$

Not available

535 07 86-01

Husqvarna 535078601

TRANSFORMER

Note: GB

$

$

Not available

535 07 65-01

Husqvarna 535076501

DECAL

$

$

Not available

535 05 05-01

Husqvarna 535050501

STAPLES/100CT

$

$

Not available

535 08 88-01

Husqvarna 535088801

STAPLES, CHARGE STATION
(Superseded to 535088901)

$

$

Not available

535 07 87-01

Husqvarna 535078701

TRANSFORMER

Note: CH

$

$

Not available
