G4000 (8837-0) - Generac 3,600 Watt Portable Generator G4000 Generator No. 66847 Parts Diagram

3,600 Watt Portable Generator

G4000 Generator No. 66847 Parts Diagram

  • Title

1

Briggs & Stratton 65189

ENGINE- 7 HP Kawasaki (FG300-DSX)

$

$

Currently unavailable

2

Briggs & Stratton 66836

CLAMP, Fuel Line

$

$

Currently unavailable

3

Briggs & Stratton 67200

BRACKET, Exhaust Muffler Support

$

$

Currently unavailable

4

Briggs & Stratton 70628

RIVET- 3mm diameter

$

$

Currently unavailable

5

Briggs & Stratton 66399

MUFFLER, Exhaust (with Spark Arrestor)

$

$

Currently unavailable

6

Briggs & Stratton 22097

LOCKWASHER- M6
(Superseded to 5022097)

$2.99

$

Usually ships in 2-12 days

0

7

Briggs & Stratton 56768

CAPSCREW, Hex Head - M10-1.50 x 90mm

$

$

Not available

8

Briggs & Stratton 51755

CAPSCREW, Hex Head - M10-1.50 x 16mm

$

$

Currently unavailable

9

UNKNOWN

$

$

Not available

9A

Briggs & Stratton 66835A

LINE, Fuel- 6mm ID x 110mm long

$

$

Currently unavailable

9B

Briggs & Stratton 66835B

LINE, Fuel- 6mm ID x 60mm long

$

$

Currently unavailable

10

Briggs & Stratton 70642

MOUNT, Vibration
(Superseded to 70642GS)

$31.99

$

In Stock, only 3 left!

0

11

Briggs & Stratton 70644

SCREW, Pan Head - M8-1.25 x 20mm
(Superseded to 70644GS)

$4.49

$

Usually ships in 2-12 days

0

12

Briggs & Stratton 49810

FLATWASHER- M8
(Superseded to 7049810YP)

$128.99

$

Usually ships in 2-12 days

0

13

Briggs & Stratton 67022

GROMMET, Wire Outlet
(Superseded to 67022GS)

$3.49

$

Usually ships in 2-12 days

0

14

Briggs & Stratton 66365C

HOUSING, Engine Adapter

$

$

Currently unavailable

15

Briggs & Stratton 39253

CAPSCREW, Hex Head - M8-1.25 x 20mm
(Superseded to 39253GS)

$3.49

$

Usually ships in 2-12 days

0

16

Briggs & Stratton 66389

FAN, Cooling

$

$

Not available

17

Briggs & Stratton 66816

ROTOR ASSY

$

$

Currently unavailable

18

Briggs & Stratton 65791

BEARING, Ball
(Superseded to 65791GS)

$34.99

$

Usually ships in 2-12 days

0

19

Briggs & Stratton 65795

RECTIFIER, Battery Charge
(Superseded to 65795GS)

$

$

Not available

20

Briggs & Stratton 66448F

BOLT, Rotor

$

$

Currently unavailable

21

Briggs & Stratton 67205

STATOR ASSY

$

$

Not available

22

Briggs & Stratton 66825

CARRIER, Rear Bearing

$

$

Currently unavailable

23

Briggs & Stratton 66449F

BOLT, Stator- M6-1.00 x 140mm

$

$

Not available

24

Briggs & Stratton 66849

SCREW (Taptite)- M5-0.80 x 16mm
(Superseded to 66849GS)

$4.99

$

In Stock, only 1 left!

0

25

Briggs & Stratton 66386

BRUSH
(Superseded to 66386GS)

$23.99

$

In Stock, only 4 left!

0

26

Briggs & Stratton 67025

COVER, Bearing Carrier

$

$

Currently unavailable

27

Briggs & Stratton 45771

NUT, Hex - M8-1.25

$

$

Not available

28

Briggs & Stratton 67107

BOARD, Circuit- Voltage Regulator
(Superseded to 67107GS)

$302.99

$

Usually ships in 2-12 days

0

29

Briggs & Stratton 70629

SCREW, Pan Head - M8-1.25 x 40mm

$

$

Currently unavailable

30

Briggs & Stratton 52619

SCREW, Machine- M5-0.80 x 20mm
(Superseded to 52619GS)

$1.99

$

Usually ships in 2-12 days

0

31

Briggs & Stratton 67444

WASHER, Serrated- M5

$

$

Currently unavailable

32

Briggs & Stratton 51716

NUT, Hex - M5-0.80
(Superseded to 51716GS)

$2.99

$

Usually ships in 2-12 days

0

33

Briggs & Stratton 67435

NUT, Wing (Grounding)- M5-0.80

$

$

Currently unavailable

34

Briggs & Stratton 67210

DECAL- Ground
(Superseded to 67210GS)

$8.99

$

Usually ships in 2-12 days

0

35

Briggs & Stratton 67451

FLATWASHER (Special)- M5

$

$

Currently unavailable

36

Briggs & Stratton 67462

DIODE ASSY
(Superseded to 67462GS)

$22.99

$

Usually ships in 2-12 days

0

37

UNKNOWN

$

$

Not available

39

UNKNOWN

$

$

Not available

40

UNKNOWN

$

$

Not available

42

UNKNOWN

$

$

Not available

43

UNKNOWN

$

$

Not available

44

UNKNOWN

$

$

Not available
