GC 9520KW (7084449) - Snapper Grounds Cruiser Utility Vehicle, 9.5hp Kawasaki Rear Frame Group Parts Diagram

Grounds Cruiser Utility Vehicle, 9.5hp Kawasaki

Rear Frame Group Parts Diagram

  • Title

1

Snapper 7012068

RING, REAR LIFT ARM
(Superseded to 7012068YP)

$5.99

$

Usually ships in 2-12 days

0

2

Snapper 7015446

HSB, 3/8-24 X 1-1/2
(Superseded to 7015446YP)

$5.99

$

Usually ships in 2-12 days

0

3

Snapper 7072495

SWIVEL (3/8" THRU HOLE)
(Superseded to 7072495SM)

$26.99

$

In Stock, only 1 left!

0

4

Snapper 7028036

FRICTION PACK SPRING
(Superseded to 7028036YP)

$7.49

$

Usually ships in 2-12 days

0

5

Snapper 7029258

BUSHING-SUSPENSION
(Superseded to 7029258YP)

$8.49

$

In Stock, Qty 20+

0

6

Snapper 7029263

SLEEVE-SUSPENSION
(Superseded to 7029263YP)

$26.99

$

Usually ships in 2-12 days

0

7

Snapper 7034162

5/16 COTTER PIN, SELF LOCKING
(Superseded to 704030)

$4.49

$

In Stock, Qty 7

0

8

Snapper 7035496

BEARING, .750 ID
(Superseded to 7035496YP)

$8.99

$

In Stock, only 2 left!

0

9

See "Fuel Tank Group" illustration and parts list

$

$

Not available

10

Snapper 7058635

WELDMENT, TUBE SUPPORT

$

$

Not available

11

Snapper 7058636

WELDMENT, SPEED CONTROL SHAFT
(Superseded to 7058636YP)

$66.99

$

Usually ships in 2-12 days

0

12

Snapper 7058639

GROUP, DRIVE BASE

Note: (See "Drive Base Group" illustration and parts list)

$

$

Currently unavailable

13

Snapper 7058640

GROUP, CVT AXLE

Note: (See "Axle Group" illustration and parts list)

$

$

Currently unavailable

14

Snapper 7058650

ASSEMBLY, PLATE/SEAL
(Superseded to 7058650YP)

Note: (See "Axle Group" illustration and parts list)

$162.99

$

In Stock, only 1 left!

0

15

Snapper 7058686

WELDMENT, DUMP BED PIVOT
(Superseded to 7058686YP)

$50.99

$

Usually ships in 2-12 days

0

16

Snapper 7058912

AIR FILTER ASSEMBLY
(Superseded to 7058912YP)

Note: (See "Air Filter Assembly" illustration and parts list)

$444.99

$

Usually ships in 2-12 days

0

17

Snapper 7072563

BRKT., SPEED CONTROL X-SHAFT
(Superseded to 7072563YP)

$18.99

$

Usually ships in 2-12 days

0

18

Snapper 7072943

FRAME, LH REAR
(Superseded to 7072943YP)

$170.99

$

Usually ships in 2-12 days

0

19

Snapper 7072944

FRAME, RH REAR

$

$

Currently unavailable

20

Snapper 7072945

STIFFENER, CVT FRAME

$

$

Not available

21

Snapper 7072962

BUMPER, RUBBER

$

$

Not available

22

Snapper 7073002

ROD, UPPER NEUTRAL RETURN

$

$

Not available

23

Snapper 7073021

BRKT., GAS TANK
(Superseded to 7073021YP)

$176.99

$

Usually ships in 2-12 days

0

24

Snapper 7073054

BRKT., AIR CLEANER MOUNTING
(Superseded to 7073054YP)

$21.99

$

Usually ships in 2-12 days

0

25

Snapper 7073062

CHANNEL, FRAME STIFFENER

$

$

Not available

26

Snapper 7073106

CHANNEL, SUBFRAME CONNECT
(Superseded to 7073106YP)

$36.99

$

Usually ships in 2-12 days

0

27

Snapper 7073190

PIN, BED LATCH STRIKER
(Superseded to 7073190YP)

$21.99

$

Usually ships in 2-12 days

0

28

Snapper 7073485

FUEL PUMP
(Superseded to 7073471YP)

$410.99

$

In Stock, only 1 left!

0

29

Snapper 7073486

REGULATOR/RECTIFIER, KAWASAKI
(Superseded to 7073503YP)

$483.99

$

Usually ships in 2-12 days

0

30

Snapper 7090815

HWST, 3/8-16 X 3/4
(Superseded to 703950)

$5.99

$

In Stock, only 3 left!

0

31

Snapper 7091298

HEX NYLON INSERT NUT 5/16-18 YZ
(Superseded to 703902)

$3.99

$

In Stock, Qty 20+

0

32

Snapper 7091299

HNYL, 3/8-16, YZ
(Superseded to 703117)

$3.99

$

In Stock, Qty 20+

0

33

Snapper 7091495

HHCS, 1/4-20 X 3/4 GR 5 YZ
(Superseded to 703925)

$4.49

$

Usually ships in 2-12 days

0

34

Snapper 7091518

HEX NYLOCK NUT 3/8-24
(Superseded to 703901)

$3.49

$

In Stock, Qty 5

0

35

Snapper 7091528

WASHER, .375 X.875 X.083
(Superseded to 703302)

$4.49

$

In Stock, Qty 20+

0

36

Snapper 7091588

HFLB 3/8-16 X 3/4-YZ
(Superseded to 703955)

$4.49

$

In Stock, Qty 9

0

37

Snapper 7091603

1/4-20 HEX NYLON INSERT NUT
(Superseded to 703232)

$4.49

$

In Stock, Qty 20+

0

38

Snapper 7091811

HFLB, 5/16-18 X .625-YZ
(Superseded to 7091811SM)

$3.99

$

In Stock, only 2 left!

0

39

Snapper 7091814

HHCS, 1/4-20 X 1.25 YZ
(Superseded to 7091814SM)

$3.99

$

Usually ships in 2-12 days

0

40

Snapper 7091891

HFLB 3/8-16 X 1.0-YZ
(Superseded to 7091891YP)

$3.49

$

Usually ships in 2-12 days

0

41

Snapper 7091905

HFLB, 5/16-18 x 7/8-YZ
(Superseded to 7091905SM)

$4.49

$

Usually ships in 2-12 days

0

42

Snapper 7090799

RHSSNB, 5/16-18 x 5/8-YZ
(Superseded to 703447)

Note: Was 91918

$4.49

$

In Stock, Qty 18

0

43

Snapper 7092052

HHCS, 3/8-16 X 5.5 - YZ
(Superseded to 7092052YP)

$5.49

$

Usually ships in 2-12 days

0
