GC-SSZ-48 - Scag Grass Catcher (SN: 3660001 - 3669999) Bucket Support Components (Upper) Parts Diagram

Grass Catcher

Bucket Support Components (Upper) Parts Diagram

  • Title

1

Scag 48135-07

Hose, 6" x 48"

Note: (Model SSZ With A 48" Deck)

$146.99

$

Usually ships in 2-12 days

0

Scag 48135-08

Hose, 6" x 24"

Note: (Model SSZ With A 52, 61" Deck)

$83.99

$

Usually ships in 2-12 days

0

2

Scag 48136-01

Clamp, Hose

$30.99

$

Usually ships in 2-12 days

0

3

Scag 48909

Elbow, Grass Catcher

$82.99

$

Usually ships in 2-12 days

0

4

Scag 46512

Cover Assembly, Grass Catcher

Note: (Includes Items 5, 6, 7, 12, 13 & 16)

$

$

Not available

5

Scag 48928

Deflector, Grass Catcher

$83.99

$

Usually ships in 2-12 days

0

6

Scag 421348

Backing Plate, Deflector

$

$

Not available

7

Rivet, 3/16 X .625"

$

$

Not available

8

Scag 421300

Handle

$

$

Not available

9

Scag 04003-12

Bolt, 5/16-18 x .75" Carriage

$0.99

$

In Stock, Qty 15

0

10

Scag 48137-03

Strap, Rubber

$

$

Not available

11

Scag 04021-10

Nut, 5/16-18 Elastic Stop

$0.99

$

In Stock, Qty 20+

0

12

Scag 481017-01

Seal Rubber

$53.99

$

Usually ships in 2-12 days

0

13

Scag 421446

Screen
(Superseded to 421689)

$

$

Not available

14

Scag 421421

Hinge, Left Hand

$

$

Not available

15

04017 26

Capscrew, 5/16-18 x .75" Serrated Flange

$

$

Not available

16

Scag 04041-20

Washer, Pop Rivet

$

$

Currently unavailable

17

Scag 421418

Plate, Hinge Backing

$16.99

$

Usually ships in 2-12 days

0

18

Scag 421947

Stiffener, Grass Catcher Hopper

$

$

Not available

19

Scag 46841

Hopper Assy., Grass Catcher With Decal

Note: (Incl. 421947)

$

$

Not available

20

Scag 421949

Backing Plate, Handle

$17.99

$

Usually ships in 2-12 days

0
