GHT 180 LE - Weed Eater Hedge Trimmer, Type 1 Handle & Blade Assembly Type 1 Parts Diagram

Hedge Trimmer, Type 1

Handle & Blade Assembly Type 1 Parts Diagram

  • Title

1

Poulan 530054133

Assy-Leadwire/Switch
(Superseded to 545172901)

Note: (Incl. #2)

$13.84

$

Usually ships in 3-10 days

0

2

Poulan 530029954

Switch-Ignition

$4.99

$

Usually ships in 3-10 days

0

3

Poulan 530055763

Assy-Rear Handle & Tank
(Superseded to 530071655)

$

$

Not available

4

Poulan 530015828

Washer-Clutch

$4.99

$

In Stock, only 1 left!

0

5

Poulan 530014396

Kit-Clutch Assy.

$

$

Not available

6

Poulan 530056069

Assy-Drum

$36.99

$

Usually ships in 3-10 days

0

7

Poulan 530014399

Assy-Gear Box
(Superseded to 530071931)

Note: (Incl. #9-11)

$

$

Not available

8

Poulan 530015886

Screw

$6.49

$

In Stock, Qty 17

0

9

Poulan 530016013

Bearing-Gear

$6.49

$

Usually ships in 3-10 days

0

10

Poulan 530036228

Assy-Pinion

$

$

Not available

11

Poulan 530015805

Screw
(Superseded to 530015886)

$6.49

$

In Stock, Qty 17

0

12

Poulan 530032121

Bushing-Blade

$

$

Not available

13

Poulan 530036046

Plate-Isolator

$7.49

$

Usually ships in 3-10 days

0

14

Poulan 530015934

Screw

$4.99

$

In Stock, only 1 left!

0

15

Poulan 530029916

Cover-Gear Box Plate

$6.49

$

In Stock, only 2 left!

0

16

Poulan 530069355

Kit-Drive Gear Ass'y.

Note: (Incl. #12)

$

$

Not available

17

Poulan 530029948

Seal-Blade (Felt)

$3.99

$

Usually ships in 3-10 days

0

18

Poulan 530403228

Assy-Blade 19"

$

$

Not available

19

Poulan 530029946

Spring

$3.99

$

In Stock, only 4 left!

0

20

Poulan 530036965

Assy-Fuel Cap
(Superseded to 577858601)

$7.49

$

In Stock, Qty 7

0

21

Poulan 530015770

Screw

$

$

Not available

22

Poulan 530053900

Lockout-Throttle

$3.99

$

Usually ships in 3-10 days

0

23

Poulan 530015934

Screw

$4.99

$

In Stock, only 1 left!

0

24

Poulan 530038305

Cover-Handle

$4.99

$

Usually ships in 3-10 days

0

25

Poulan 530015940

Screw

$6.49

$

In Stock, Qty 9

0

26

Poulan 530015775

Screw

$6.49

$

In Stock, only 2 left!

0

27

Poulan 530029958

Lever-Trigger

$3.99

$

Usually ships in 3-10 days

0

28

Poulan 530036123

Spring-Trigger

$3.99

$

In Stock, only 4 left!

0

29

Poulan 530053884

Trigger

$3.99

$

In Stock, only 3 left!

0

30

Poulan 530015955

Screw

$3.99

$

Usually ships in 3-10 days

0

31

Poulan 530094992

Handle-Front

$

$

Not available
