GM 5700 - Green Machine 5,700 Watt Generator General Assembly (Part 1) Parts Diagram

5,700 Watt Generator

General Assembly (Part 1) Parts Diagram

  • Title

1

Homelite 661603001

Bolt (M5 x 10, Flange Hd.)

$

$

Not available

2

Homelite 519785002

Brush Cover

$

$

Not available

3

Homelite 638703001

Ground Lug

$1.49

$

Usually ships in 3-7 days

0

4

Homelite 660596009

Bolt, Stator 5.7kW

$

$

Not available

5

Homelite 661603002

Bolt, Mounting Brush Assembly

$

$

Not available

6

Homelite 290441001

Brush Assembly

$

$

Not available

7

Homelite 661557003

Bolt (5/16-24 x 6-5/8 in., Hex Hd.)

$

$

Not available

8

Homelite 638678002

Lock Washer (5/16 in.)

$1.49

$

Usually ships in 3-7 days

0

9

Homelite 660596002

Bolt, Wiz (3/8-18 x 1-1/4 in.)

$1.49

$

Usually ships in 3-7 days

0

10

Homelite 640331001

Adapter Housing

$44.99

$

Usually ships in 3-7 days

0

11

Homelite 661603001

Bolt, Mounting AVR

$

$

Not available

12

Homelite 290440002

Automatic Voltage Regulator

$

$

Not available
