GX610 K1 TXF2 (GCAC) - Honda Engine, Made in Japan (SN: GCAC-2000001 - GCAC-2059999) CONTROL BOX Parts Diagram

Engine, Made in Japan

CONTROL BOX Parts Diagram

  • Title

1

Honda 31612-ZE2-003

SEE PART DETAILS - PRI; CASE, CONTROL

Note: (Honda Code 2095875).

$20.99

$

In Stock, only 1 left!

0

2

Honda 31614-ZE2-003

SEE PART DETAILS - PRI; BRACKET, CASE MOUNTING

Note: (Honda Code 2095883).

$17.99

$

Usually ships in 3-6 days

0

3

Honda 31620-ZG5-003

RECTIFIER ASSY., REGULATOR (20A)
(Superseded to 31620-ZG5-033)

Note: (Honda Code 4210225).

$184.99

$

Usually ships in 3-6 days

0

4

Honda 32103-759-000

BRACKET, WIRE HARNESS CLIP

Note: (Honda Code 3508561).

$3.99

$

Usually ships in 3-6 days

0

5

Honda 32105-ZJ1-800

SEE PART DETAILS - PRI; SUB-WIRE HARNESS ASSY.

Note: (Honda Code 4543930).

$53.99

$

In Stock, only 1 left!

0

6

Honda 32340-ZJ1-841

BOX ASSY., CONTROL

Note: (Honda Code 6225668).

$

$

Currently unavailable

7

Honda 32345-ZJ1-811

PANEL, CONTROL

Note: (Honda Code 4210282).

$

$

Currently unavailable

8

Honda 32349-ZJ1-840

STAY, CONTROL BOX

Note: (Honda Code 6225676).

$43.99

$

Usually ships in 3-6 days

0

9

Honda 32902-892-003

BAND

Note: (Honda Code 0947457).

$4.49

$

Usually ships in 3-6 days

0

10

Honda 35100-ZJ1-841

SWITCH ASSY., COMBINATION
(Superseded to 35100-ZJ1-842)

Note: (Honda Code 6225767).

$114.99

$

Usually ships in 3-6 days

0

11

Honda 35111-880-003

KEY
(Superseded to 35111-880-013)

Note: (Honda Code 0485706).

$10.99

$

In Stock, Qty 8

0

12

Honda 36103-ZE1-000

HOLDER, STOP SWITCH WIRE

Note: (Honda Code 1429141).

$2.49

$

Usually ships in 3-6 days

0

13

Honda 87529-ZE2-860

MARK, CONTROL BOX (EXTERNAL-REGULATOR)

Note: (Honda Code 4212486).

$

$

Currently unavailable

14

Honda 90380-MA6-010

SEE PART DETAILS - PRI; SCREW, SPECIAL (6X12)

Note: (Honda Code 1490648).

$3.99

$

Usually ships in 3-6 days

0

15

Honda 32171-GJ1-003

CLIP, WIRE HARNESS

Note: (Honda Code 1858554).

$4.99

$

Usually ships in 3-6 days

0

16

Honda 90676-SA8-003

BAND, WIRE HARNESS (150MM) (BLUE)

Note: (Honda Code 1352103).

$6.49

$

Usually ships in 3-6 days

0

17

Honda 91408-ZJ1-810

TUBE, CORD (30MM)

Note: (Honda Code 4210498).

$8.99

$

Usually ships in 3-6 days

0

18

Honda 91504-750-003

CLIP, WIRE HARNESS

Note: (Honda Code 1803444).

$3.99

$

Usually ships in 3-6 days

0

19

Honda 93500-04012-0H

SEE PART DETAILS - PRI; SCREW, PAN (4X12)

Note: (Honda Code 0285643).

$1.49

$

In Stock, Qty 10

0

20

Honda 94001-04080-0S

SEE PART DETAILS - PRI; NUT, HEX. (4MM)

Note: (Honda Code 0562116).

$1.49

$

Usually ships in 3-6 days

0

21

Honda 94111-04800

WASHER, SPRING (4MM)

Note: (Honda Code 0346114).

$1.49

$

Usually ships in 3-6 days

0

22

Honda 95701-06010-00

SEE PART DETAILS - PRI; BOLT, FLANGE (6X10)

Note: (Honda Code 2410876).

$1.49

$

In Stock, Qty 20+

0

23

Honda 95701-06012-00

SEE PART DETAILS - PRI; BOLT, FLANGE (6X12)

Note: Use from Engine SN .. (Honda Code 2105799).

$1.99

$

In Stock, Qty 20+

0

24

Honda 98200-32500

FUSE, BLADE (25A)

Note: (Honda Code 4210589).

$2.99

$

Usually ships in 3-6 days

0
