HF 1954 (55AF3DAW150) - Cub Cadet Walk-Behind Mower, Kawasaki Standard Handle Assembly WT Parts Diagram

Walk-Behind Mower, Kawasaki

Standard Handle Assembly WT Parts Diagram

  • Title

1

Cub Cadet 912-3017

Hex Nut, 3/8-16
(Superseded to 712-3017)

$4.49

$

In Stock, Qty 20+

0

2

Cub Cadet 00011211

Black Neutral Latch Grip, 1.25"

$8.99

$

In Stock, only 2 left!

0

3

Cub Cadet 00011453

Hex Nut, Jam 3/8-24

$3.99

$

Usually ships in 3-6 days

0

4

Cub Cadet 00012116

End Rod, 3/8 Female

Note: NLA

$

$

Not available

5

Cub Cadet 00012118

Knob, 1-3/8 x 1-19/64, 3/8-24

$

$

Not available

6

Cub Cadet 00012152

Lock Nut, Nylon Insert, 1/4-20

$4.49

$

In Stock, only 1 left!

0

7

Cub Cadet 936-0169

Lock Washer, 3/8
(Superseded to 736-0169)

$3.99

$

In Stock, Qty 20+

0

8

Cub Cadet 00012158

Flat Washer, 3/8

$4.49

$

In Stock, Qty 10

0

9

Cub Cadet 00012165

Nut, 5/16-18

$4.99

$

In Stock, only 1 left!

0

10

Cub Cadet 00012169

Flat Washer, 5/16

$4.49

$

In Stock, only 2 left!

0

11

Cub Cadet 712-04065

Lock Nut, Nylon Insert, 3/8-16

$3.99

$

In Stock, Qty 20+

0

12

Cub Cadet 00012562

Cotter Pin, 3/32 x 1/2

$

$

Not available

13

Cub Cadet 00013131

HHCS, 1/4-20 x .75

$6.49

$

In Stock, only 1 left!

0

14

Cub Cadet 00013198

HHCS, Standard, 5/16 -18 x 2
(Superseded to 710-3103)

$4.49

$

In Stock, Qty 13

0

15

Cub Cadet 712-04177

Lock Nut, SS, Nylon Insert, 1/4-28

$6.99

$

In Stock, only 4 left!

0

16

Cub Cadet 00015903

Operator Presence Switch

$44.99

$

In Stock, only 1 left!

0

17

Cub Cadet 00030378

Black Plastic Handle Grip, 4-5/8

$

$

Not available

18

Cub Cadet 01001579

Belt Tightener Pivot

$

$

Not available

19

Cub Cadet 00069943

Speed Control Assembly, Hydro LH

$

$

Not available

20

Cub Cadet 00069952

Speed Control Assembly, Hydro RH

$

$

Not available

21

Cub Cadet 00071310

Latch, LH Neutral Hydro

$

$

Not available

22

Cub Cadet 00071326

Latch, RH Neutral Hydro

$

$

Not available

23

Cub Cadet 00071691

Hydro Spacer Control Rod

$11.99

$

Usually ships in 3-6 days

0

24

Cub Cadet 00072892

Hydro Bushing Control Rod

$

$

Not available

25

Cub Cadet 00072930

Hydro Control Rod, Short

$

$

Not available

26

Cub Cadet 00072937

Hydro Control Rod, Long

$

$

Not available

27

Cub Cadet 00073092

Hydro Speed Control Rod

$

$

Not available

28

Cub Cadet 00077495

Friction Washer

$

$

Not available

29

Cub Cadet 00090995

Hex Nut, Dead Man Switch

$

$

Not available

30

Cub Cadet 01000643

Carriage Bolt, 3/8-16 x 1.0

$5.49

$

In Stock, Qty 9

0

31

Cub Cadet 01001377-0637

Neutral Safety Mounting Switch

$

$

Not available

32

Cub Cadet 02002360-0637

Operator's Presence Control, RH

$38.99

$

In Stock, only 1 left!

0

33

Cub Cadet 02002362-0637

Operator's Presence Control, LH

$

$

Not available

34

Cub Cadet 01001708

Hydro Handle Assembly

$

$

Not available

35

Cub Cadet 01001714

Control Sleeve, Black

$11.99

$

Usually ships in 3-6 days

0

36

Cub Cadet 01001715

Operator's Presence Sleeve, Yellow

$11.99

$

Usually ships in 3-6 days

0

37

Cub Cadet 01001716

Harness Assembly Adapter

$

$

Not available

38

Cub Cadet 01001717

Snap Mounting Switch
(Superseded to 925-3166)

$16.99

$

In Stock, Qty 20+

0

39

Cub Cadet 01006085

Label Handle

$

$

Not available

40

Cub Cadet 01001863

Retension Spring

$

$

Not available

41

Cub Cadet 01001864

Hex Index Washer Screw, TT, 10-24, .500
(Superseded to 1767754)

$

$

Not available

42

Cub Cadet 01001919

Shoulder Screw, .38 x .412, 1/4-28
(Superseded to 938-0826)

$12.99

$

In Stock, Qty 7

0

43

Cub Cadet 01001972

HHCS, 5/16-18, 2.00

$3.99

$

Usually ships in 3-6 days

0

45

Cub Cadet 01002171

Decal, Parking Brake

$

$

Not available

46

Cub Cadet 02002358-0637

Control Lever Assembly

$

$

Not available

47

Cub Cadet 01006669

Label, Hydro Mower Panel

$

$

Not available
