HRK 52 (59A40136727) - Cub Cadet Yanmar Tractor Hydraulic Chute Rotator Attachment Hydraulic Chute Rotator Parts Diagram

Tractor Hydraulic Chute Rotator Attachment

Hydraulic Chute Rotator Parts Diagram

  • Title

1

Cub Cadet YS-006798

HEX HEAD CAP SCREW, 5/16-18 X 1.25 GR 5

$

$

Not available

2

Cub Cadet YS-007433

LOCK NUT, HEX 5/16-18 GR 5

$

$

Not available

3

Cub Cadet YS-008152

FLAT WASHER, 5/16 SAE

$

$

Not available

4

Cub Cadet YS-011194

ADAPTER UNION, STR

$

$

Not available

5

Cub Cadet YS-011271

DUST CAP, BLACK

$

$

Not available

6

Cub Cadet YS-011313

COUPLER NOSE

$

$

Not available

7

Cub Cadet YS-013534

SPOCKET

$

$

Not available

8

Cub Cadet YS-014099

HOSE SLEEVE

$

$

Not available

9

Cub Cadet YS-014132

PLASTIC TIE

$

$

Not available

10

Cub Cadet YS-017156

HYDRAULIC HOSE, 1/4 X 87

$

$

Not available

11

Cub Cadet YS-023218

RESTRICTOR

$

$

Not available

12

Cub Cadet YS-023300

HYD MOTOR, SIDE PORT

$

$

Not available

13

Cub Cadet YS-754097

GUARD SPROCKET PLATE

$

$

Not available
