HS724 K1 TA (SZBE) - Honda 24" Snow Blower, Made in Japan (SN: SZBE-2400001 - SZBE-9999999) TENSIONER ARM (1) Parts Diagram

24" Snow Blower, Made in Japan

TENSIONER ARM (1) Parts Diagram

  • Title

1

Honda 22437-767-000

SPRING, WHEEL TENSION RETURN

$8.49

$

In Stock, only 2 left!

0

2

Honda 22438-738-A00

SPRING, AUGER TENSIONER RETURN

$10.99

$

In Stock, only 2 left!

0

3

Honda 22439-736-A00

SPRING, BRAKE ARM

$4.49

$

In Stock, Qty 9

0

4

Honda 22455-767-000

STAY, TENSIONER SPRING

$10.99

$

Usually ships in 3-6 days

0

5

Honda 22526-V41-000

ARM, AUGER TENSIONER

Note: Use from Frame SN 2401560.

$40.99

$

Usually ships in 3-6 days

0

6

Honda 22512-V41-W00

SEE PART DETAILS - PRI; ARM, AUGER BRAKE

$32.99

$

In Stock, Qty 5

0

7

Honda 22514-V41-000

COLLAR, ROLLER

Note: Use from Frame SN 2401560.

$3.99

$

Usually ships in 3-6 days

0

7

Honda 22514-736-000

COLLAR, ROLLER

Note: Use up to Frame SN 2401559.

$5.49

$

Usually ships in 3-6 days

0

8

Honda 22520-767-000

ARM, WHEEL TENSIONER

$95.99

$

In Stock, only 1 left!

0

9

Honda 22524-730-000

BUSH, TENSIONER ARM

$11.99

$

In Stock, only 3 left!

0

10

Honda 22530-736-A00

ROLLER

$46.99

$

In Stock, only 2 left!

0

11

Honda 50319-736-A00

RUBBER, STOPPER

$4.99

$

Usually ships in 3-6 days

0

12

Honda 51176-767-000

BRACKET, TENSION ARM

$24.99

$

Usually ships in 3-6 days

0

13

Honda 90013-883-000

BOLT, FLANGE (6X12) (CT200)

$2.49

$

In Stock, Qty 20+

0

14

Honda 90101-736-000

BOLT, ROLLER

$6.99

$

Usually ships in 3-6 days

0

15

Honda 90115-659-003

NUT, SELF-LOCK (8MM) (CLINCH)

$1.49

$

In Stock, Qty 20+

0

16

Honda 90501-736-A00

WASHER, BRAKE ARM

$4.49

$

Usually ships in 3-6 days

0

17

Honda 94050-08000

NUT, FLANGE (8MM)

$1.49

$

In Stock, Qty 20+

0

18

Honda 94102-12800

WASHER, PLAIN (12MM)

$

$

Not available

19

Honda 94201-30180

PIN, SPLIT (3.0X18)

$1.49

$

In Stock, Qty 20+

0

20

Honda 22524-730-000

BUSH, TENSIONER ARM

Note: Use up to Frame SN 2401559.

$11.99

$

In Stock, only 3 left!

0

20

Honda 54429-762-003

BUSH, CHANGE ARM

Note: Use from Frame SN 2401560.

$4.49

$

In Stock, Qty 5

0
