HUV 4420 - Husqvarna 4x4 Utility Vehicle (2006-11) Front Seats and Cup Holder Parts Diagram

4x4 Utility Vehicle

Front Seats and Cup Holder Parts Diagram

  • Title

1

Husqvarna 603000229

Tape, Vinyl Foam 1/8" x 3/4"

$

$

Not available

2

Husqvarna 603000998

Closeout, Driver Side

$

$

Not available

3

Husqvarna 603000999

Closeout, Passenger Side

$

$

Not available

4

Husqvarna 603001049

Pan, Center, Closeout

$

$

Not available

5

Husqvarna 531308251

Asm, Bucket Seat Adjustable

Note: (includes items 6 through 18)

$

$

Not available

6

Husqvarna 603000125

Hinge Plate

$

$

Not available

7

Husqvarna 603000736

Rivet, 1/4 X .438 Blind

$

$

Not available

8

Husqvarna 603000774

Screw, 6m-1.00 X 10mm Hex Head

$

$

Not available

9

Husqvarna 603000777

Seat Holder Cup

$

$

Not available

10

Husqvarna 603000875

Bolt, Flange Head, M8 X 30.0

$

$

Not available

11

Husqvarna 603001298

Nut,m8,all Metal Lock

$3.49

$

In Stock, Qty 11

0

12

Husqvarna 603001093

Pan, Seat, Driver Asm

$

$

Not available

13

Husqvarna 603001102

Decal, Hot Surface Warning

$

$

Not available

14

Husqvarna 603001137

Adjuster, Forward/Aft

$

$

Not available

15

Husqvarna 603001138

Adjuster, Slider

$

$

Not available

16

Husqvarna 603001145

Washer, Bell

$

$

Not available

17

Husqvarna 603004079

Seat, Bucket, Gray

$655.99

$

In Stock, only 1 left!

0

18

Husqvarna 603000058

Lockwasher, 1/4 Helical Split

$

$

Not available

19

Assembly, Bucket Seat w/Spacers

Note: (includes items 20 through 29)

$

$

Not available

20

Husqvarna 603000125

Hinge Plate

$

$

Not available

21

Husqvarna 603000579

Screw, M8-125 X 22 Hex-Head

$

$

Not available

22

Husqvarna 603000184

Lockwasher, 8mm Split

$

$

Not available

23

Husqvarna 603000689

Pan, Seat, Passenger

$

$

Not available

24

Husqvarna 603000736

Rivet, 1/4 X .438 Blind

$

$

Not available

25

Husqvarna 603000774

Screw, 6m-1.00 X 10mm Hex Head

$

$

Not available

26

Husqvarna 603000777

Seat Holder Cup

$

$

Not available

27

Husqvarna 603001102

Decal, Hot Surface Warning

$

$

Not available

28

Husqvarna 603004079

Seat, Bucket, Gray

$655.99

$

In Stock, only 1 left!

0

29

Husqvarna 603000058

Lockwasher, 1/4 Helical Split

$

$

Not available

30

Husqvarna 603001161

Console, Center, Drink Holder

$

$

Not available

31

Husqvarna 603000695

Rivet, Removable, Tuflok 1/4"

$

$

Not available
