HUV 4421 D - Husqvarna 4x4 Utility Vehicle, Diesel (2008-01) Floorboard Parts Diagram

4x4 Utility Vehicle, Diesel

Floorboard Parts Diagram

  • Title

1

Husqvarna 603004504

Instl, Floorboard

Note: (includes items 2 through 8)

$

$

Not available

2

Husqvarna 603003045

WASHER, 5/16 TYPE B FLAT

$

$

Not available

3

Husqvarna 603001308

LOCK NUT, FLG M8 X 1.25 NYLON

$

$

Not available

4

Husqvarna 603004458

FLOORBOARD, LOWER

$

$

Not available

5

Husqvarna 603004459

FLOORBOARD, UPPER

$

$

Not available

6

Husqvarna 603004460

3/16 X 1.19 ALUM RIVET, BLK

$

$

Not available

7

Husqvarna 603004503

BRACKET SUPPORT - FLOORBOARD

$

$

Not available

8

Husqvarna 603004502

Bolt, M8 X 125 X 110

$

$

Currently unavailable
