HWTB - Bear Cat Trimmer, 163cc Briggs & Stratton (SN: H06826 & Above) Drive Parts Diagram

Trimmer, 163cc Briggs & Stratton

Drive Parts Diagram

  • Title

1

Bear Cat 12314

BEARING, 3/4 BALL

$23.99

$

Usually ships in 3-7 days

0

2

15098

WASHER, 3/4" SAE FLAT ZP

$

$

Not available

3

Bear Cat 15117-00

BOLT, 5/16 X 3/4 FLANGE NC

$1.99

$

Usually ships in 3-7 days

0

4

15122-00

BOLT, 5/16 X 1-1/2 FLANGE NC

$

$

Not available

5

Bear Cat 15131

SCREW, 5/16-18 X 5/8 SQ HD SET

$

$

Not available

6

15176

SCREW, 11/32-12 X 7/8 FLANGE T-AB

$

$

Not available

7

15258-00

BOLT, 5/16 X 1-1/4 FLANGE NC

$

$

Not available

8

Bear Cat 15372

KEY, 3/16" X 1.00" LG SQUARE

$1.49

$

Usually ships in 3-7 days

0

9

Bear Cat 15904-00

NUT, 5/16-18 NYLOCK FLANGE

$

$

Not available

10

ENGINE, BRIGGS 163CC VERTICAL (FOR SERVICE SEE ENGINE OWNER'S MANUAL OR NEAREST BRIGGS & STRATTON INDUSTRIAL ENGINE DEALER)

$

$

Not available

11

Bear Cat 33670-00

SPACER, TRIMMER SPINDLE

$15.99

$

Usually ships in 3-7 days

0

12

Bear Cat 33671-00

CASTING, TRIMMER SPINDLE HUB

$115.99

$

Usually ships in 3-7 days

0

13

Bear Cat 33676-00

PULLEY, ENGINE 4.0 X .875 B GROOVE

$45.99

$

Usually ships in 3-7 days

0

14

Bear Cat 33677-00

BELT, AX48

$41.99

$

Usually ships in 3-7 days

0

15

Bear Cat 33684-00

SPACER, 1-1/16 OD X 14 GA X 1.630

$31.99

$

Usually ships in 3-7 days

0

16

33801-00

STRING, 20" X .155 DIA. CROSS-FIRE

$

$

Not available

17

Bear Cat 71629-12

MOWBALL, CAST TRIMMER PAINTED

$

$

Not available

18

Bear Cat 72705-12

DISK, TRIMMER HEAD

$

$

Not available

19

Bear Cat 72781-12

SPACER, TRIMMER HEAD

$

$

Not available

20

Bear Cat 73373-00

WELDMENT, SPINDLE HW MODELS

$72.99

$

Usually ships in 3-7 days

0

21

Bear Cat 74654-12

PLATE, SPINDLE CASTING MOUNT

$

$

Not available
