I 4550 B (UT-10862) - Homelite Chainsaw Carburetor - Muffler - Air Filter Parts Diagram

Chainsaw

Carburetor - Muffler - Air Filter Parts Diagram

  • Title

1

Homelite UP00126A

Muffler Kit (45cc)

Note: Includes items 2-7

$

$

Not available

2

Homelite 06839

Muffler Gasket
(Superseded to 900848001)

$1.49

$

In Stock, only 1 left!

0

3

Homelite PS04525

Screw-Square Hd.
(Superseded to 660626001)

$

$

Not available

4

Homelite 81206

Nut-Locking Hex (10-32)
(Superseded to 671079001)

$1.49

$

In Stock, Qty 16

0

5

Homelite 07394

Screen, Spark
(Superseded to A07402)

$

$

Not available

6

Homelite PS00087

Deflector, Muffler (45cc)

$

$

Not available

7

Homelite 95922

Screw
(Superseded to 660624001)

$

$

Not available

8

Homelite UP00499

Carburetor Assy (Int'l 45cc)

Note: Includes items 9-10

$

$

Not available

9

Homelite 98339

Carburetor Gasket
(Superseded to 900843001)

$

$

Not available

10

Homelite 07589

Flange Nut (10-24)

$1.49

$

In Stock, only 1 left!

0

11

Homelite A07596B

Throttle Cable
(Superseded to 900845001)

$

$

Not available

12

Homelite 06840A

Gasket, Heat Dam

$

$

Not available

13

Homelite 04916

Heat Dam

$

$

Not available

14

Homelite 06873

Seal, Heat Dam

$

$

Not available

15

Homelite 82539

Screw, Truss Hd. Taptite (10-24 x 7/8")
(Superseded to 660616001)

$

$

Not available

16

Homelite 06852

Screw, Carburetor

$2.99

$

In Stock, only 1 left!

0

17

Homelite 82541

Screw, Thread Form (10-14 x 1/2")

$1.49

$

In Stock, only 3 left!

0

18

Homelite 12789

Washer, Retaining

$

$

Not available

19

Homelite 0745434

Fuel Line (Tank to Carburetor 8 1/2")

$

$

Not available

20

Homelite 0745416

Fuel Line (Carburetor to Purge Bulb 4")

$3.49

$

Usually ships in 3-7 days

0

21

Homelite 04907

Carburetor Grommet

$

$

Not available

22

Homelite UP06753A

Air Filter Kit

Note: Includes items 23-25

$

$

Not available

23

Homelite 04938

Air Filter Cover

$

$

Not available

24

Homelite PS05070

Pre Filter (In engine housing)

$

$

Not available

25

Homelite 82617

Screw-Slotted Pan Hd. (8-16 x 5/8")

$1.49

$

In Stock, only 2 left!

0

26

Homelite PS03969

Rod, Choke
(Superseded to PS06280)

$

$

Not available

27

Homelite 04937

Air Filter Plate

$

$

Not available

28

Homelite 08939

Spring Clip (Choke Rod)

$

$

Not available
