IS Z (5901079) - Ferris ISZ Series 61" Zero-Turn Mower, 25hp Kohler (SN: 2269 & Above) Brake Group Parts Diagram

ISZ Series 61" Zero-Turn Mower, 25hp Kohler

Brake Group Parts Diagram

  • Title

1

Ferris 5045936B

COVER MOUNT PLATE

$

$

Currently unavailable

2

Ferris 5045892B

BRACKET, Cover Mount

$

$

Currently unavailable

3

Ferris 5022308

BODY CLIP, 5/16-18-7GA MATERIAL
(Superseded to 5022308SM)

$5.99

$

In Stock, Qty 10

0

4

Ferris 5045931B

INSTRUMENT PANEL MOUNT

$13.99

$

Usually ships in 2-12 days

0

5

Ferris 5025013X8

BOLT, 3/8-16 X 1" GD5 CZ
(Superseded to 5025013X8SM)

$3.99

$

In Stock, only 4 left!

0

6

Ferris 5025156

WASHER, 3/8 SAE
(Superseded to 5025156FS)

$3.49

$

Usually ships in 2-12 days

0

7

Ferris 5025128

NUT, 3/8-16 Hex Serrated Flange
(Superseded to 5025128SM)

$3.49

$

Usually ships in 2-12 days

0

8

Ferris 5025013X6

BOLT, 3/8-16 X 3/4" GD5 CZ
(Superseded to 5025013X6SM)

$3.99

$

Usually ships in 2-12 days

0

9

Ferris 5025011X8

BOLT, 5/16-18 X 1 GD5 YZ
(Superseded to 5025011X8FS)

$3.49

$

Usually ships in 2-12 days

0

10

Ferris 5025155

WASHER, 5/16" SAE

$

$

Currently unavailable

11

Ferris 5045634B

BRAKE COVER PANEL

$

$

Currently unavailable

12

Ferris 5022030

VALVE, Fuel Shut Off

$43.99

$

In Stock, only 1 left!

0
