iZ 25 (968999771) - Husqvarna Zero-Turn Mower (2008-01) Ignition System Parts Diagram

Zero-Turn Mower

Ignition System Parts Diagram

  • Title

1

Husqvarna 539110953

CONSOLE

$

$

Not available

2

Husqvarna 539131627

SWITCH, PTO 10 AMP
(Superseded to 597520401)

$100.99

$

In Stock, Qty 13

0

3

Husqvarna 539103275

THROTTLE CABLE

$34.99

$

In Stock, only 1 left!

0

4

Husqvarna 539990362

SCREW 1/4-20 x 5/8

$4.99

$

In Stock, Qty 12

0

5

Husqvarna 539990052

WASHER, 1/4 SPLIT LOCK

$3.99

$

Usually ships in 3-10 days

0

6

Husqvarna 539976977

NUT #10-24 HEX NYLOC

$

$

Not available

7

Husqvarna 539990411

HCS #10-24 x 1/2

$3.99

$

Usually ships in 3-10 days

0

8

Husqvarna 539107541

IGNITION SWITCH
(Superseded to 532175566)

$12.99

$

In Stock, Qty 20+

0

9

Husqvarna 539110074

HOUR METER
(Superseded to 576179401)

$34.99

$

In Stock, Qty 9

0

10

Husqvarna 539107544

KEY, IGNITION
(Superseded to 532140401)

$6.49

$

In Stock, Qty 20+

0

11

Husqvarna 539990598

WASHER, 1/4 FLAT

$

$

Not available

12

Husqvarna 539102617

SCREW #10-24 x 7/8 SLT HD

$3.99

$

In Stock, only 3 left!

0

13

Husqvarna 539976934

HCS 5/16-18 x 3/4
(Superseded to 596030501)

$3.99

$

In Stock, Qty 20+

0

14

Husqvarna 539990717

NUT 5/16-18 HEX NYLOC
(Superseded to 596583702)

$3.99

$

In Stock, Qty 20+

0

15

Husqvarna 539102758

CABLE, NEGATIVE

$15.99

$

Usually ships in 3-10 days

0

16

Husqvarna 539102759

INSULATOR-BATTERY

$4.99

$

In Stock, only 2 left!

0

17

Husqvarna 539130208

CHOKE CNTRL / LZ25 ONLY
(Superseded to 539109954)

$35.99

$

Usually ships in 3-10 days

0

18

Husqvarna 539102436

BATTERY, DRY
(Superseded to 579411601)

$

$

Not available

19

Husqvarna 539106899

HOLD DOWN, BATTERY

$60.99

$

In Stock, only 1 left!

0

20

Husqvarna 539103306

CABLE, POSITIVE
(Superseded to 586108201)

$8.99

$

In Stock, only 2 left!

0

21

Husqvarna 539113791

HARNESS

$

$

Not available

22

Husqvarna 539110815

WIRE CLIP PUSH-MOUNT

$3.49

$

In Stock, only 1 left!

0

23

Husqvarna 539113792

SWITCH, BRAKE

$12.99

$

In Stock, Qty 20+

0
