K 950 Rescue - Husqvarna Rescue Saw (2007-01)

Rescue Saw

K 950 Rescue - Husqvarna Rescue Saw (2007-01) > Parts Diagrams (15) > CARBURETOR DETAILS

  • Title
503 28 04-02

1

CARBURETTORIncl. 2-24

Part# 503 28 04-02

OEM Warranty Repair Part for Husqvarna

Usually leaves our warehouse in 1 business day

Your price: $205.70

506 27 14-01

2

MET.RETENTION SCREW

Part# 506 27 14-01

OEM Warranty Repair Part for Husqvarna Construction

Usually leaves our warehouse in 4 to 6 business days

Your price: $2.57

503 53 36-01

3

DIAPHRAGM

Part# 503 53 36-01

OEM Warranty Repair Part for Husqvarna

Usually leaves our warehouse in 4 to 6 business days

Your price: $4.64

506 25 64-02

4

INSERT

Part# 506 25 64-02

OEM Warranty Repair Part for Husqvarna Construction

Usually leaves our warehouse in 3 to 4 business days

Your price: $4.73

501 82 18-01

5

THROTTLE SH."E"RING

Part# 501 82 18-01

OEM Warranty Repair Part for Husqvarna

Usually leaves our warehouse in 1 business day

Your price: $7.82

506 25 85-01

6

DIAPHRAGMA, B

Part# 506 25 85-01

OEM Warranty Repair Part for Husqvarna Construction

Usually leaves our warehouse in 3 to 4 business days

Your price: $14.93

506 25 84-01

7

DIAPHRAGMA, B

Part# 506 25 84-01

OEM Warranty Repair Part for Husqvarna Construction

Usually leaves our warehouse in 3 to 4 business days

Your price: $14.93

501 22 21-01

8

PIN RETAINING SCREW

Part# 501 22 21-01

OEM Warranty Repair Part for Husqvarna

Usually leaves our warehouse in 4 to 6 business days

Your price: $4.64

501 22 20-01

9

LEVERA

Part# 501 22 20-01

OEM Warranty Repair Part for Husqvarna

Usually leaves our warehouse in 1 business day

Your price: $4.64

505 31 65-50

10

INLET

Part# 505 31 65-50

OEM Warranty Repair Part for Husqvarna

Usually leaves our warehouse in 4 to 6 business days

Your price: $10.45

501 22 25-01

11

SPRINGA

Part# 501 22 25-01

OEM Warranty Repair Part for Husqvarna

Usually leaves our warehouse in 1 business day

Your price: $3.48

501 22 03-01

12

PLUG WELCHA, F

Part# 501 22 03-01

OEM Warranty Repair Part for Husqvarna Construction

Not available

501 48 52-01

13

PIN RETAINING SCREW

Part# 501 48 52-01

OEM Warranty Repair Part for Husqvarna

Usually leaves our warehouse in 4 to 6 business days

Your price: $3.48

506 28 63-01

14

SPRING THROTT.RETURN

Part# 506 28 63-01

OEM Warranty Repair Part for Husqvarna Construction

Usually leaves our warehouse in 3 to 4 business days

Your price: $2.57

503 57 87-01

15

IDLE SPEED SCREW

Part# 503 57 87-01

OEM Warranty Repair Part for Husqvarna

Usually leaves our warehouse in 1 business day

Your price: $5.25

503 57 86-01

16

SPEED SCREW RET BALL

Part# 503 57 86-01

OEM Warranty Repair Part for Husqvarna

Usually leaves our warehouse in 3 to 4 business days

Your price: $4.64

501 22 04-01

17

CHOKE FRICTION BALL

Part# 501 22 04-01

OEM Warranty Repair Part for Husqvarna

Usually leaves our warehouse in 1 business day

Your price: $10.45

501 22 05-01

18

SPRING

Part# 501 22 05-01

OEM Warranty Repair Part for Husqvarna

Usually leaves our warehouse in 1 business day

Your price: $3.34

503 98 82-01

19

SCREEN

Part# 503 98 82-01

OEM Warranty Repair Part for Husqvarna

Usually leaves our warehouse in 4 to 6 business days

Your price: $5.80

503 53 39-01

20

TUBE CONNECTORA

Part# 503 53 39-01

OEM Warranty Repair Part for Husqvarna

Usually leaves our warehouse in 4 to 6 business days

Your price: $10.45

501 22 12-01

21

FUEL PUMP DIAPHRAMA, B

Part# 501 22 12-01

OEM Warranty Repair Part for Husqvarna

Usually leaves our warehouse in 1 business day

Your price: $8.13

501 22 13-01

22

FUEL PUMPA, B

Part# 501 22 13-01

OEM Warranty Repair Part for Husqvarna

Usually leaves our warehouse in 1 business day

Your price: $16.96

506 28 68-01

23

FUEL PUMP COVER

Part# 506 28 68-01

OEM Warranty Repair Part for Husqvarna Construction

Usually leaves our warehouse in 3 to 4 business days

Your price: $6.77

501 22 15-01

24

SCREW

Part# 501 22 15-01

OEM Warranty Repair Part for Husqvarna

Usually leaves our warehouse in 4 to 6 business days

Your price: $2.31

506 27 63-01

25

REPAIR KITIncl. 6, 7, 9, 11, 12, 20, 21, 22

Part# 506 27 63-01

OEM Warranty Repair Part for Husqvarna Construction

Usually leaves our warehouse in 1 business day

Your price: $23.10

506 25 88-01

26

DIAPHRAGMIncl. 6, 7, 21, 22

Part# 506 25 88-01

OEM Warranty Repair Part for Husqvarna Construction

Usually leaves our warehouse in 3 to 4 business days

Your price: $14.93

506 29 09-01

27

THROTTLE SHAFT(KIT)Kit C

Part# 506 29 09-01

OEM Warranty Repair Part for Husqvarna Construction

Usually leaves our warehouse in 3 to 4 business days

Your price: $29.82

506 29 10-01

28

SEALING, KITKit D

Part# 506 29 10-01

OEM Warranty Repair Part for Husqvarna Construction

Usually leaves our warehouse in 3 to 4 business days

Your price: $7.53

506 29 11-01

29

CHOKE SHAFT (KIT)Kit E

Part# 506 29 11-01

OEM Warranty Repair Part for Husqvarna Construction

Usually leaves our warehouse in 3 to 4 business days

Your price: $18.27

506 29 13-01

30

JETKit F

Part# 506 29 13-01

OEM Warranty Repair Part for Husqvarna Construction

Usually leaves our warehouse in 3 to 4 business days

Your price: $75.37
