KS 614 - Poulan Pro Chainsaw CUTTING ARM ASSEMBLY Parts Diagram

Chainsaw

CUTTING ARM ASSEMBLY Parts Diagram

  • Title

1

Poulan 507433879

Decal (not a serviceable part)

Note: (not a serviceable part)

$

$

Not available

2

Poulan 503200005

Screw
(Superseded to 503215325)

$5.99

$

In Stock, Qty 9

0

3

Poulan 503200045

Bolt

$6.99

$

Usually ships in 3-10 days

0

4

Poulan 503200008

Screw

$2.99

$

In Stock, Qty 5

0

5

Poulan 507476682

Bracket

$

$

Not available

6

Poulan 507433876

Screw

$8.99

$

Usually ships in 3-10 days

0

7

Poulan 505262172

Cam

$

$

Not available

8

Poulan 507433877

Washer

$

$

Not available

9

Poulan 506057103

Spindle Arm Cover

$61.99

$

Usually ships in 3-10 days

0

10

Poulan 507433858

Belt

$66.99

$

Usually ships in 3-10 days

0

11

Poulan 506071802

Pulley
(Superseded to 506354701)

$56.99

$

Usually ships in 3-10 days

0

12

Poulan 503230104

Washer

$6.49

$

In Stock, only 2 left!

0

13

Poulan 506070103

Spindle Arm

$129.24

$

Usually ships in 3-10 days

0

14

Poulan 507433848

Arm Bar

$

$

Not available

15

Poulan 507433849

Bracket

$54.99

$

Usually ships in 3-10 days

0

16

Poulan 5074338698

Cover

$23.99

$

Usually ships in 3-10 days

0

17

Poulan 503251003

Ball Bearing

$20.76

$

Usually ships in 3-10 days

0

18

Poulan 506070801

Spacer

$13.99

$

Usually ships in 3-10 days

0

19

Poulan 506036201

Washer

$8.07

$

In Stock, only 2 left!

0

20

Poulan 506028401

Washer

$15.64

$

Usually ships in 3-10 days

0

21

Poulan 506036202

Washer

$9.49

$

Usually ships in 3-10 days

0

22

Poulan 506036204

Washer

$8.49

$

Usually ships in 3-10 days

0

23

Poulan 506034501

Plate

$13.99

$

Usually ships in 3-10 days

0

24

Poulan 725232771

Bolt
(Superseded to 503200003)

$6.49

$

Usually ships in 3-10 days

0

25

Poulan 506143202

Stud

$13.99

$

Usually ships in 3-10 days

0

26

Poulan 506028572

Shaft
(Superseded to 506298371)

$93.99

$

Usually ships in 3-10 days

0

27

Poulan 506070701

Spacer

$22.99

$

Usually ships in 3-10 days

0

28

Poulan 506070901

Collar

$51.99

$

Usually ships in 3-10 days

0

29

Poulan 506028803

Sleeve
(Superseded to 506028825)

$29.99

$

In Stock, Qty 12

0

30

Poulan 506139501

Washer
(Superseded to 506139511)

$29.99

$

Usually ships in 3-10 days

0

31

Poulan 506139602

Bolt

$

$

Not available

32

Poulan 506072147

Cutting Arm Ass'y.

$

$

Not available

33

Poulan 506029804

Handle

$

$

Not available

34

Poulan 506029503

Spacer

$2.99

$

Usually ships in 3-10 days

0

35

Poulan 503230005

Washer

$6.49

$

In Stock, only 3 left!

0

36

Poulan 506029601

Spring

$5.49

$

Usually ships in 3-10 days

0

37

Poulan 735310920

E-Ring

$7.49

$

In Stock, Qty 12

0

38

Poulan 506138901

Shield

$

$

Not available

39

Poulan 506138201

Guard Ass'y. Complete

Note: (Incl. 38)

$

$

Not available
