L2400 (8906-0) - Generac 2,250 Watt Portable Generator Mounting Base No. 70649 Parts Diagram

2,250 Watt Portable Generator

Mounting Base No. 70649 Parts Diagram

  • Title

1

Briggs & Stratton 70632

ENGINE- Briggs & Stratton 8 HP Manual Start

$

$

Currently unavailable

2

Briggs & Stratton 70635

BASE, Mounting

$

$

Currently unavailable

3

Briggs & Stratton 70637

LOOP, Cradle End

$

$

Currently unavailable

4

Briggs & Stratton 70638A

SUPPORT, Fuel Tank - Right

$

$

Currently unavailable

5

Briggs & Stratton 70638

SUPPORT, Fuel Tank - Left

$

$

Currently unavailable

6

Briggs & Stratton 69661

TANK, Fuel - 2.3 Gallons

$

$

Not available

7

Briggs & Stratton 64680B

COVER, Spark Plug Access
(Superseded to 64680BGS)

$7.99

$

Usually ships in 2-12 days

0

8

Briggs & Stratton 69658

CAP, Fuel Tank

$

$

Currently unavailable

9

Briggs & Stratton 66391B

GAUGE, Fuel Level

$

$

Not available

10

Briggs & Stratton 52749

SCREW - M5-0.80 x 12mm

$

$

Currently unavailable

11

Briggs & Stratton 56893

SCREW - No. 10 - 32 x 1/2"
(Superseded to 56893GS)

$3.49

$

In Stock, only 1 left!

0

12

Briggs & Stratton 45771

NUT, Hex - M8-1.25

$

$

Not available

13

Briggs & Stratton 48031C

CLAMP, Fuel Hose - 1/4"

$

$

Not available

14A

Briggs & Stratton 47662BA

HOSE, Fuel - 7" long

$

$

Currently unavailable

14B

Briggs & Stratton 47662E

HOSE, Fuel - 9" long

$

$

Currently unavailable

15

Briggs & Stratton 58442

SCREW

$

$

Currently unavailable

16

Briggs & Stratton 66831

RIVET- 4mm

$

$

Not available

17

Briggs & Stratton 66450

HANDLE- Plastic

$

$

Not available

18

Briggs & Stratton 48506

DECAL- "GENERAC" Logo

$

$

Currently unavailable

19

Briggs & Stratton 70642

MOUNT, Vibration
(Superseded to 70642GS)

$31.99

$

In Stock, only 3 left!

0

20

Briggs & Stratton 22129

WASHER, Lock - 5/16"
(Superseded to 22129GS)

$2.99

$

In Stock, only 2 left!

0

21

Briggs & Stratton 22259

NUT, Hex- 5/16"-18
(Superseded to 22259GS)

$3.49

$

Usually ships in 2-12 days

0

22

Briggs & Stratton 66880

SHIELD, Heat

$

$

Currently unavailable

23

Briggs & Stratton 24489

SCREW

$

$

Currently unavailable

24

Briggs & Stratton 25433

LUG, Grounding

$

$

Not available

25

Briggs & Stratton 70634

SUPPORT, Generator Rear

$

$

Currently unavailable

26

Briggs & Stratton 64183

SCREW, Pan Head - 5/16"-18 x 3/4"

$

$

Currently unavailable

27

Briggs & Stratton 70653

SCREW, Pan Head- 5/16"-18 x 1-1/2"
(Superseded to 70653GS)

$6.99

$

Usually ships in 2-12 days

0

28

Briggs & Stratton 70630

STRAINER, Fuel

$

$

Currently unavailable

29

Briggs & Stratton 67210A

DECAL- Ground
(Superseded to 67210AGS)

$3.49

$

Usually ships in 2-12 days

0

30

Briggs & Stratton 69674

DECAL- Fuel Caution

$

$

Currently unavailable

31

Briggs & Stratton 68740

FILTER, Fuel
(Superseded to 68740GS)

$11.99

$

Usually ships in 2-12 days

0
