LC-407 (18A-407-190) - White Outdoor Lawn Boss 19" Walk-Behind Mower, Electric (1998) Cord & Switch Assembly Parts Diagram
Lawn Boss 19" Walk-Behind Mower, Electric
Cord & Switch Assembly Parts Diagram
White Outdoor 625-0050
Exploded View Of Cord & Switch Assembly
$
$
Not available
White Outdoor 710-1150
Scr. Hx . Lock #7-19 X 1.00 Lg.
$
$
Not available
$
$
Not available
White Outdoor 724-0248
Cord w/Plug
$
$
Not available
$39.99
$
Usually ships in 3-6 days
White Outdoor 725-1731
Switch
$
$
Not available
White Outdoor 731-1985
Upper Switch Housing
$
$
Not available
White Outdoor 731-1986
Lower Switch Housing
$
$
Not available
White Outdoor 731-1987
Control Lever
$
$
Not available
White Outdoor 732-0935
Torsion Spring
$
$
Not available
