Lo-Boy - International Harvester Cub Lo-Boy Tractor (SN: 224705 - 229999) Adjustable Front Axle Attachment (Special) Parts Diagram

Cub Lo-Boy Tractor

Adjustable Front Axle Attachment (Special) Parts Diagram

  • Title

25

Cub Cadet IH-350782-R11

TUBE ASSY, TIE ROD

$

$

Currently unavailable

26

Cub Cadet IH-355063-R11

TUBE ASSY, TIE ROD

Note: (TRACTORS EQUIPPED WITH HIGH CLEARANCE ATTACHMENT)

$

$

Currently unavailable

26

Cub Cadet IH-350784-R1

CLAMP, TIE ROD

$

$

Not available

Cub Cadet IH-103026

NUT, 3/8-24 HEX
(Superseded to 912-0121)

$3.99

$

In Stock, Qty 20+

0

Cub Cadet IH-181370

SCREW, 3/8-24 X 1-1/4 HEX-HD CAP

$

$

Currently unavailable

Cub Cadet IH-103321

WASHER, 3/8 MED LOCK

$

$

Currently unavailable

27

Cub Cadet IH-350778-R1

TIE ROD

$

$

Not available

Cub Cadet IH-114496

NUT, 1/2-20 HEX JAM

$

$

Currently unavailable

28

Cub Cadet IH-350758-R1

BUSHING, FRONT AXLE PIVOT

$

$

Currently unavailable

29

Cub Cadet IH-350764-R1

PIN, FRONT AXLE CLAMP

$

$

Currently unavailable

Cub Cadet IH-108630

PIN, 1/8 X 7/8 COT.

$

$

Not available

30

Cub Cadet IH-350761-R1

BUSHING, STEERING KNUCKLE POST

$

$

Currently unavailable

31

Cub Cadet IH-20167-R1

SCREW, 1/2-20 X 3 HEX-HD CAP FRONT AXLE CLAMP

$

$

Currently unavailable

Cub Cadet IH-103028

NUT, 1/2-20 HEX

$

$

Currently unavailable

Cub Cadet IH-103323

WASHER, 1/2 MED LOCK
(Superseded to 936-0921)

$4.49

$

In Stock, Qty 20+

0

32

Cub Cadet IH-350756-R11

AXLE

Note: (W/TWO BUSHINGS IH-350758-R1, FRONT)

$

$

Currently unavailable

32

Cub Cadet IH-355064-R11

AXLE

Note: (W/TWO BUSHINGS, IH-350758-R1 FRONT TRACTORS EQUIPPED WITH HIGH CLEARANCE ATTACHMENT)

$

$

Currently unavailable

33

Cub Cadet IH-351957-R1

WASHER, FRONT AXLE PIVOT THRUST

$

$

Not available

34

Cub Cadet IH-109454

FITTING, 1/4-28 NS TAPER STR LUB

$

$

Not available

35

Cub Cadet IH-350762-R1

CLAMP, FRONT AXLE

$

$

Currently unavailable

36

Cub Cadet IH-350759-R11

EXTENSION, FRONT AXLE

Note: (W/TWO BUSHINGS, IH-350761-R1)

$

$

Currently unavailable

37

Cub Cadet IH-109454

FITTING, 1/4-28 NS TAPER STR LUB

$

$

Not available

Cub Cadet IH-355429-R91

PACKAGE, STEERING KNUCKLE ARM

Note: (REPLACES IH-350776-R2 & IH-350777-R2 SERIAL NO. 138484 & BELOW; CONSISTS OF 1 ARM IH-355428-R1, 1 NUT IH-114496, 1 SCREW IH-355427-R1)

$

$

Currently unavailable

Cub Cadet IH-355428-R1

ARM

Note: (NOT AVAILABLE SEPARATELY)

$

$

Currently unavailable

Cub Cadet IH-114496

NUT

$

$

Currently unavailable

Cub Cadet IH-355427-R1

SCREW

$

$

Currently unavailable

Cub Cadet IH-43528D

SCREW, LOCKING STEERING KNUCKLE ARM

Note: (SERIAL NO. 118687 & BELOW)

$

$

Currently unavailable

Cub Cadet IH-218440

NUT, 1/2-13 HEX. JAM

$

$

Currently unavailable

Cub Cadet IH-355427-R1

SCREW, LOCKING STEERING KNUCKLE ARM

Note: (SERIAL NOS. 118688 TO 138484)

$

$

Currently unavailable

Cub Cadet IH-114496

NUT, 1/2-20 HEX JAM

$

$

Currently unavailable
