LT 3812 (13AC77KF897) - Columbia 38" Lawn Tractor (2013) Transmission - Single Speed Parts Diagram

38" Lawn Tractor

Transmission - Single Speed Parts Diagram

  • Title

1

MTD 918-04566

Transmission Ass’y
(Superseded to 918-04566B)

$668.99

$

In Stock, only 4 left!

0

2

MTD 647-04034C-0637

Drive Pedal Assembly
(Superseded to 647-04034E-0637)

$80.99

$

Usually ships in 3-6 days

0

3

MTD 647-04266

Shift Lever Ass’y
(Superseded to 647-04266A)

$24.99

$

In Stock, only 1 left!

0

4

MTD 710-0227

Hex Wash HD AB S-Tapp Scr #8-.50

$3.99

$

In Stock, Qty 20+

0

5

MTD 710-04484

S-Tapp Scr 5/16-18 x .75

$3.49

$

In Stock, Qty 20+

0

6

MTD 710-0599

Hex Wash S-Tapp Scr 1/4-20 x .50

$3.99

$

In Stock, Qty 20+

0

7

MTD 710-0604A

Self-tapping Screw 5/16-18 x .625

$3.99

$

In Stock, Qty 20+

0

8

MTD 710-0809

Hex Bolt 1/4-20 x 1.25

$6.49

$

In Stock, Qty 20+

0

9

MTD 710-0176

Hex Scr 5/16-18 x 2.75

$4.49

$

In Stock, only 2 left!

0

10

MTD 710-3008

Hex Bolt 5/16-18 x .75" Lg. Gr. 5

$3.99

$

In Stock, Qty 20+

0

11

MTD 711-06103

Ferrule

$3.99

$

In Stock, only 1 left!

0

12

MTD 712-04063

Flange Locknut 5/16-18 Gr. F, Nylon

$3.99

$

In Stock, Qty 20+

0

13

MTD 712-0700

Flange Nut

$10.99

$

In Stock, Qty 17

0

14

MTD 914-0209

Cotter Pin

$3.49

$

In Stock, only 1 left!

0

15

MTD 714-04040

Bow Tie Cotter Pin

$1.49

$

In Stock, Qty 20+

0

16

MTD 718-04407

Pulley Hub 5/8" Spline

$11.99

$

In Stock, Qty 11

0

17

MTD 720-04028

Shift Knob

$10.99

$

In Stock, Qty 9

0

18

MTD 725-0157

Cable Tie

$3.49

$

In Stock, only 4 left!

0

19

MTD 725-1644

Short Spring Switch

$8.99

$

In Stock, only 2 left!

0

20

MTD 726-0214

Push Cap 5/8" Dia Rod

$9.99

$

In Stock, Qty 20+

0

21

MTD 926-0320

Insulator Nut Plate

$6.49

$

In Stock, Qty 10

0

22

MTD 731-04602

Sleeve, .758 x .821 x 3.3125

$5.99

$

In Stock, only 1 left!

0

23

MTD 731-04604

Sleeve, .758 x .821 x 2.4375

$6.49

$

Usually ships in 3-6 days

0

24

MTD 732-04306

Spring, Extension, .80 OD x 3.28

$9.49

$

In Stock, Qty 14

0

25

MTD 732-04488

Spring, Extension

$5.99

$

In Stock, Qty 20+

0

26

MTD 732-0716D

Ext. Spring .59 OD x 4.00 Lg.

$12.99

$

In Stock, Qty 20+

0

27

MTD 735-0239

Foot Pad
(Superseded to 735-0239A)

$11.99

$

In Stock, Qty 7

0

28

MTD 756-04325

Flat Idler

$22.99

$

In Stock, Qty 20+

0

29

MTD 747-05244

Shift Rod (38"/42")

$3.99

$

Usually ships in 3-6 days

0

29

MTD 747-05243

Shift Rod (46")

$10.99

$

In Stock, only 3 left!

0

30

MTD 747-05186

Control Rod, Variable Speed

$14.99

$

Usually ships in 3-6 days

0

31

MTD 747-05188

Brake Rod

$11.99

$

Usually ships in 3-6 days

0

32

MTD 747-04969

Belt Keeper Rod

$6.49

$

In Stock, only 3 left!

0

34

MTD 750-0566A

Spacer .260 x .375 x 1.030 Lg.

$9.49

$

In Stock, only 4 left!

0

35

MTD 750-0802

Spacer .630 ID

$6.49

$

Usually ships in 3-6 days

0

36

MTD 954-0241A

Belt
(Superseded to 954-05040)

$45.99

$

In Stock, Qty 20+

0

37

MTD 954-04249A

Belt

$45.99

$

In Stock, Qty 20+

0

38

MTD 956-04002

Pulley, V-Type, 7.25 dia.

$25.99

$

In Stock, Qty 20+

0

39

MTD 783-04536B-0637

Pedal Support Bracket

$6.49

$

Usually ships in 3-6 days

0

40

MTD 783-04595A

Shift Bracket, Adjustable

$9.99

$

In Stock, only 4 left!

0

41

MTD 956-04015A

Variable Speed Pulley Ass’y 4.75 OD
(Superseded to 956-04015B)

$96.99

$

In Stock, Qty 20+

0

42

MTD 683-04176A

Transmission Torque Bracket
(Superseded to 783-04567B)

$8.49

$

Usually ships in 3-6 days

0

43

MTD 753-05147

Idler Bracket

$30.99

$

In Stock, only 3 left!

0

44

MTD 710-0347

Screw, 3/8-16 x 1.75

$4.99

$

In Stock, Qty 20+

0

45

MTD 710-1260A

Hex Wash. Hd. Scr. 5/16-18 x .75 Lg.

$3.49

$

In Stock, Qty 20+

0

46

MTD 712-04065

Flange Lock-Nut 3/8-16 Gr. F Nylon

$3.99

$

In Stock, Qty 20+

0

47

MTD 938-0347

Shoulder Spacer

$9.49

$

In Stock, Qty 12

0

48

MTD 753-05147

Variable Speed Bracket Ass’y

$30.99

$

In Stock, only 3 left!

0

49

MTD 710-05339

Sems Screw 5/16-24 x 0.75 Gr. 5
(Superseded to 710-05339A)

$3.99

$

In Stock, Qty 20+

0

50

MTD 710-0778

Hex Scrw 1/4-20 x 1.5

$3.99

$

In Stock, Qty 14

0

51

MTD 718-04261

Bearing Cup

$18.99

$

In Stock, Qty 17

0

52

MTD 732-04746

Spring, Extension, .94 OD x 6.75

$10.99

$

In Stock, Qty 16

0

53

MTD 736-0362

Flat Washer .22 ID x 1.25

$4.49

$

In Stock, Qty 20+

0

54

MTD 941-0600

Ball Bearing 17 x 40 x 12

$23.99

$

In Stock, Qty 20+

0

55

MTD 634-0104-0911

Wheel Assembly Complete

$509.99

$

Usually ships in 3-6 days

0

55

MTD 734-1730-0901

Tire Only

$92.99

$

In Stock, Qty 7

0

55

MTD 634-04369-0662

Rim Only

$153.99

$

Usually ships in 3-6 days

0

55

MTD 934-0255

Valve

$3.99

$

In Stock, Qty 20+

0

57

MTD 725-04363

Interlock Switch

$14.99

$

In Stock, Qty 20+

0

58

MTD 17962

Switch Plate

$4.99

$

In Stock, Qty 5

0

59

MTD 738-04237A

Shoulder Screw #10-32 x .5

$5.99

$

In Stock, Qty 20+

0

60

MTD 731-06894

Shift Plate Bearing

$5.99

$

In Stock, Qty 9

0
