M60-KW LC (53AJ8CT6050) - Cub Cadet 60" Tank Zero-Turn Mower, 29hp Kawasaki Kawasaki Electrical Assembly Parts Diagram

60" Tank Zero-Turn Mower, 29hp Kawasaki

Kawasaki Electrical Assembly Parts Diagram

  • Title

1

Cub Cadet 925-1707D

Battery, 12V 225CCA 30 Min

$

$

Not available

2

Cub Cadet 00012289

Cable, Battery, Red, 36"

$

$

Not available

3

Cub Cadet 725-0157

Tie, Cable, 3/16 x .05 x 7.4"

$3.49

$

In Stock, only 4 left!

0

4

Cub Cadet 00013131

Screw, Hex, Cap, 1/4-20 x .75

$6.49

$

In Stock, only 1 left!

0

5

Cub Cadet 00013258

Boot, 1" OD Rubber Battery-PST, Red

$9.99

$

Usually ships in 3-6 days

0

6

Cub Cadet 02003038

Electrical Conduit Clip, 3/8

$

$

Not available

7

Cub Cadet 723-3064

Strap, Battery

$27.99

$

In Stock, only 4 left!

0

8

Cub Cadet 00022560

Flange Lock, Hex Nut, 3/8-16
(Superseded to 712-05007)

$3.99

$

In Stock, Qty 20+

0

9

Cub Cadet 00032097

Nut, W/Cap, 5/8-32 Ignition
(Superseded to 00032097P)

$

$

Not available

10

Cub Cadet 710-3178

Carriage Bolt, 3/8-16 x .75 Long

$3.99

$

In Stock, Qty 20+

0

11

Cub Cadet 710-0599

Self Tapping Screw, 1/4-20 x .50

$3.99

$

In Stock, Qty 20+

0

13

Cub Cadet 01002111

Switch, Electric, PTO
(Superseded to 925-1716A)

$68.99

$

In Stock, Qty 20+

0

14

Cub Cadet 01002251

Relay, 12V 40A

$53.99

$

In Stock, only 2 left!

0

15

Cub Cadet 912-3027

Hex Flange Lock Nut, 1/4-20

$3.99

$

In Stock, Qty 20+

0

16

Cub Cadet 01003581P

Switch, Ignition, 6 Pin

$65.99

$

In Stock, Qty 20+

0

17

Cub Cadet 925-04893

Meter, Hour includes:
(Superseded to 925-04893A)

$154.99

$

Usually ships in 3-6 days

0

17

Cub Cadet 02004259

Clip

Note: (not shown)

$6.49

$

Usually ships in 3-6 days

0

18

Cub Cadet 01009623

Cable, Battery Black, 34"

$

$

Not available

19

Cub Cadet 01009816P

Light Indicator, 12V

$38.99

$

Usually ships in 3-6 days

0

20

Cub Cadet 01009905

Bracket, PTO Switch Retainer

$25.99

$

Usually ships in 3-6 days

0

21

Cub Cadet 01009921

Adaptor

$22.99

$

Usually ships in 3-6 days

0

22

Cub Cadet 02000024P

Neutral Switch
(Superseded to 925-3164A)

$37.99

$

In Stock, Qty 13

0

23

Cub Cadet 02002551-0637

Battery Bracket

$83.99

$

Usually ships in 3-6 days

0

24

Cub Cadet 02002588

Alarm, High Temp

$

$

Not available

Cub Cadet 02002951

Harness Assembly

Note: (not shown)

$260.99

$

Usually ships in 3-6 days

0

Cub Cadet 01001811

Hourmeter, Harness
(Superseded to 929-04195)

Note: (not shown)

$7.99

$

Usually ships in 3-6 days

0
