Billy Goat MV 601 SPE - Billy Goat Lawn & Litter Vacuum NOZZLE Parts Lookup with Diagrams

1

Billy Goat 350127

YOKE 1/2"-20

$22.99

$

Usually ships in 2-11 days

2

Billy Goat 350128

PIN YOKE 1/2"

$17.99

$

Usually ships in 2-11 days

3

Billy Goat 840243

SCREWCAP BUTTON HEAD, 3/8-16 X 1 1/4" PL

$0.99

$

In Stock, only 2 left!

4

Billy Goat 8172009

WASHER 3/8"SAE 13/32"X13/16"X1/16"

$1.49

$

In Stock, only 2 left!

5

Billy Goat 8161042

NUT LOCK 3/8-16 LT WT THIN ZP

$0.99

$

In Stock, Qty 11

6

Billy Goat 8041038

SCREWCAP 5/16"-18X3 1/2" HCS ZP

$0.99

$

Usually ships in 2-11 days

7

Billy Goat 8160002

NUT LOCK 5/16"-18 HEX Z/P

$0.99

$

In Stock, Qty 11

8

Billy Goat 8172020

WASHER FLAT FENDER 5/16

$0.99

$

In Stock, only 4 left!

9

Billy Goat 8161044

NUT LOCK 1/2"-13 NYLON INSERT

$0.99

$

In Stock, Qty 10

10

Billy Goat 8171002

WASHER 1/4" FLAT Z/P

$0.99

$

In Stock, Qty 6

11

Billy Goat 400424

LABEL WARNING OPEI

$3.99

$

Usually ships in 2-11 days

12

Billy Goat 8024050

BOLT CARRIAGE 5/16"-18 X 3 1/2" ZP

$0.99

$

Usually ships in 2-11 days

13

Billy Goat 520156

PIN ROLL 1/4" X 1"

$1.49

$

Usually ships in 2-11 days

14

Billy Goat 8172011

WASHER 1/2" SAE Z/P

$0.99

$

In Stock, only 3 left!

15

Billy Goat 840118

NOZZLE MV VAC ASSEMBLY

$488.99

$

Usually ships in 2-11 days

16

Billy Goat 840019

PLUG HOSE 5" VAC

$24.99

$

Usually ships in 2-11 days

17

Billy Goat 840024

HANDLE LOWER BRACE MV

$73.99

$

Usually ships in 2-11 days

18

Billy Goat 840101

WHEEL AND TIRE 14" SMOOTH

$115.99

$

Usually ships in 2-11 days

19

Billy Goat 840104

AXLE FRONT WA VAC

$155.99

$

Usually ships in 2-11 days

20

Billy Goat 840155

BRACKET HGT ADJ WA WA/LABEL MV VAC

$117.99

$

Usually ships in 2-11 days

21

Billy Goat 8041004

SCREWCAP 1/4"-20X3/4" HCS ZP

$0.99

$

Usually ships in 2-11 days

22

Billy Goat 840034

LINK HGT ADJ SP VAC

$21.99

$

Usually ships in 2-11 days

23

Billy Goat 840041

BRACKET NOZZLE WEAR GUARD VAC

$23.99

$

Usually ships in 2-11 days

24

Billy Goat 840029

ROD CONNECT HGT ADJ

$13.99

$

Usually ships in 2-11 days

25

Billy Goat 840073

BUSHING 0.5 ID 0.625 OD X 0.25

$4.49

$

Usually ships in 2-11 days

26

Billy Goat 840119

ROD HANDLE CRANK ASSEMBLY

$87.99

$

Usually ships in 2-11 days

27

Billy Goat 840057

HANDLE CRANK

$16.99

$

Usually ships in 2-11 days

28

Billy Goat 840078

BUSHING 3/8 ID X 1/2 OD X 3/8

$4.49

$

Usually ships in 2-11 days

29

Billy Goat 840158

WASHER LOCK 1/4" TWISTED TOOTH

$4.49

$

Usually ships in 2-11 days

30

Billy Goat 840207

INTERNAL TOOTH WASHER BRASS

$0.99

$

Usually ships in 2-11 days

31

Billy Goat 840135

NOZZLE COVER MV VAC ASSY

$306.99

$

Usually ships in 2-11 days

32

Billy Goat 840259

LABEL BADGING MV

$12.99

$

Usually ships in 2-11 days

33

Billy Goat 840035

SCREW SHEETROCK 1" LONG

$0.99

$

In Stock, Qty 10

34

Billy Goat 840054

LABEL HGT ADJ MV VAC

$2.99

$

Usually ships in 2-11 days

35

Billy Goat 8122082

SCREW SM 1/4"X3/4" TYPE A HX WF

$1.49

$

Usually ships in 2-11 days

36

Billy Goat 840088

BRACKET NOZZLE COVER REINFORCE

$54.99

$

Usually ships in 2-11 days

37

Billy Goat 8024021

BOLT CARRIAGE 1/4" X 3/4"

$0.99

$

Usually ships in 2-11 days

38

Billy Goat 900455

NUT WHIZ 1/4"-20 WASH FACE

$1.49

$

In Stock, only 3 left!

100

Billy Goat 8172007

WASHER 1/4"SAE9/32"X5/8"X1/16"

$0.99

$

In Stock, Qty 11

195

Billy Goat 840017

BEARING 1/2 ID

(Superseded to 900774) 

$8.99

$

In Stock, only 1 left!

201

Billy Goat 840117

SOLENOID ELECTRIC START

$39.99

$

Usually ships in 2-11 days

202

Billy Goat 840198

BRACKET SOLONOID MOUNT

$22.99

$

Usually ships in 2-11 days

209

Billy Goat 8181007

WASHER LOCK 1/4" EXTERNAL TOOTH

$0.99

$

In Stock, Qty 8

211

Billy Goat 8142001

NUT 1/4"-20 FIN HEX Z/P

$0.99

$

Usually ships in 2-11 days

221

Billy Goat 840082

SCREW PLASTITE 1/4-10 X 3/4 HWH ZP

$1.49

$

In Stock, Qty 5

MV 601 SPE - Billy Goat Lawn & Litter Vacuum NOZZLE Parts Diagram

NOZZLE Parts Diagram
