MZ 48 - Husqvarna 48" Zero-Turn Mower (Original) WHEELS & TIRES Parts Diagram

48" Zero-Turn Mower

WHEELS & TIRES Parts Diagram

  • Title

9

Husqvarna 595528801

Pins

Note: For 96766590101, 97045570100, 97045560100

$3.99

$

Usually ships in 3-10 days

0

14

Husqvarna 595316401

Washers

Note: For 96766590101, 97045570100, 97045560100

$3.99

$

In Stock, Qty 18

0

4

Husqvarna 539102535

GREASE CAP
(Superseded to 595281301)

Note: For 96766590100, 967262801-00, 967262701-00

$7.49

$

In Stock, Qty 20+

0

Husqvarna 582746301

TIRE.22X10-10.K513.SERVICE

$239.99

$

In Stock, only 1 left!

0

13

Husqvarna 587653902

NUT.1/2-20.UNF-2B.GR.8.YL
(Superseded to 587653903)

Note: For 96766590101, 97045570100, 97045560100

$4.99

$

In Stock, Qty 14

0

6

Husqvarna 539102851

SEAL

$8.49

$

In Stock, Qty 19

0

9

Husqvarna 539102889

COTTER PIN 1/8 X 2
(Superseded to 539124704)

Note: For 96766590100, 967262801-00, 967262701-00

$

$

Not available

11

Husqvarna 596241501

Nuts

Note: For 96766590101, 97045570100, 97045560100

$14.99

$

In Stock, only 4 left!

0

17

Husqvarna 539105307

ROLLER BEARING-CAGED 3 1/4'

Note: For 96766590101, 97045570100, 97045560100

$13.99

$

In Stock, Qty 12

0

14

Husqvarna 819182212

WASHER.9/16 X 1 3/8 X 12 GA.
(Superseded to 595316401)

Note: For 96766590100, 967262801-00, 967262701-00

$3.99

$

In Stock, Qty 18

0

20

Husqvarna 539912234

VALVE STEM TR-412

Note: Tire Valvestem - Not Shown

$4.99

$

In Stock, Qty 15

0

2

Husqvarna 581199501

TIRE.ASSEM.CASTER.13X6.5-6.SIL

Note: For 96766590101, 97045570100, 97045560100

$239.99

$

In Stock, Qty 12

0

18

Husqvarna 539105522

TIRE - SMOOTH 13X6.50-6

Note: For 96766590101, 97045570100, 97045560100

$119.99

$

Usually ships in 3-10 days

0

10

Husqvarna 594946501

GSPW Screws

Note: For 96766590101, 97045570100, 97045560100

$7.49

$

In Stock, Qty 8

0

11

Husqvarna 539102852

NUT 1"C HEX SLOTTED
(Superseded to 596241501)

Note: For 96766590100, 967262801-00, 967262701-00

$14.99

$

In Stock, only 4 left!

0

19

Husqvarna 539103300

ZERK
(Superseded to 542164296)

Note: For 96766590101, 97045570100, 97045560100

$3.99

$

Usually ships in 3-10 days

0

13

Husqvarna 539101173

LUG NUT 1/2F
(Superseded to 587653903)

Note: For 96766590100, 967262801-00, 967262701-00

$4.99

$

In Stock, Qty 14

0

16

Husqvarna 599405101

Shims

Note: For 96766590101, 97045570100, 97045560100

$3.99

$

Usually ships in 3-10 days

0

5

Husqvarna 586921902

FORK.CASTER.ASM.PNT.668

$56.99

$

In Stock, only 2 left!

0

12

Husqvarna 521991101

NUT, 1/2-13 HEX FLG NYLOC ZD
(Superseded to 521991102)

$4.99

$

In Stock, Qty 20+

0

3

Husqvarna 539102543

TAPERED ROLLER BRG

$23.99

$

In Stock, Qty 7

0

1

Husqvarna 580747001

WHEEL.ASSEM.22X10-10.SILVE.ZTR

$299.99

$

In Stock, only 3 left!

0

8

Husqvarna 539103300

ZERK
(Superseded to 542164296)

Note: For 96766590101, 97045570100, 97045560100

$3.99

$

Usually ships in 3-10 days

0

4

Husqvarna 595281301

Caps

Note: For 96766590101, 97045570100, 97045560100

$7.49

$

In Stock, Qty 20+

0

8

Husqvarna 539101474

ZERK
(Superseded to 596623501)

Note: For 96766590100, 967262801-00, 967262701-00

$3.99

$

In Stock, Qty 20+

0

10

Husqvarna 539105517

HEX SCREW 1/2-13 X 9.5 GR5
(Superseded to 594946501)

Note: For 96766590100, 967262801-00, 967262701-00

$7.49

$

In Stock, Qty 8

0

7

Husqvarna 575334901

SPACER, PIVOT

$21.99

$

In Stock, Qty 5

0

15

Husqvarna 539133007

WASHER, .825 X 1.087, WAVE

Note: For 96766590101, 97045570100, 97045560100

$3.99

$

In Stock, Qty 13

0

17

Husqvarna 539102484

BEARING RETAINER

Note: For 96766590101, 97045570100, 97045560100

$5.99

$

In Stock, Qty 20+

0
