Outlaw Stand-On - Bad Boy Stand-On Mower (2014) Actuator, Pump Idler, back plate, and height indicator Assemblies Parts Diagram

Stand-On Mower

Actuator, Pump Idler, back plate, and height indicator Assemblies Parts Diagram

  • Title

1

Bad Boy 070-5200-00

Stand On Frame 2012 (54" Decks)

$

$

Not available

2

Bad Boy 039-5949-00

Stand-On Pump Idler Bracket

$39.99

$

Usually ships in 0 days

0

3

Bad Boy 019-6017-00

.635 ID Plastic Washer

$0.99

$

In Stock, only 4 left!

0

4

Bad Boy 024-6034-00

1/4" Drive in Grease Fitting

$0.99

$

In Stock, only 2 left!

0

5

Bad Boy 018-5311-00

5/8" x 4" Hex Bolt

$4.49

$

In Stock, only 1 left!

0

6

Bad Boy 013-5301-00

5/8" Nylock (1/2 Jam)

$0.99

$

In Stock, only 2 left!

0

7

Bad Boy 018-6036-00

1/2" x 2 3/4" Hex Bolt

$1.99

$

In Stock, only 2 left!

0

8

Bad Boy 013-8050-00

1/2-13 Nylon Flange Nut-Orange

$1.99

$

In Stock, Qty 20+

0

9

Bad Boy 025-7036-00

1/2 x 1/2 Spacer

$4.99

$

In Stock, only 2 left!

0

10

Bad Boy 018-2004-00

All Thread-pump Idler Tensioner

$13.99

$

In Stock, only 4 left!

0

11

Bad Boy 013-7018-00

1/2" Hex Nut

$0.99

$

In Stock, Qty 6

0

12

Bad Boy 034-2009-00

2009 Deck/Pump Idler Spring

$19.99

$

In Stock, Qty 15

0

13

Bad Boy 033-6001-00

4 3/4" Idler Pulley

$33.99

$

In Stock, Qty 20+

0

14

Bad Boy 018-4010-00

1/2" Nylcock Nut (1/2 Jam)

$1.99

$

In Stock, Qty 8

0

15

Bad Boy 035-7033-00

Actuator

$465.99

$

Usually ships in 4-7 days

0

16

Bad Boy 018-7016-00

1/2-13 x GR 5 Hex Bolt Zinc

$1.99

$

In Stock, Qty 5

0

17

Bad Boy 013-8050-00

1/2-13 Nylon Flange Nut-Orange

$1.99

$

In Stock, Qty 20+

0

18

Bad Boy 025-5337-00

.502 x .750 x 1.25 Length Spacer

$4.99

$

In Stock, only 2 left!

0

19

Bad Boy 019-8054-00

.505 Nylon Spacer

$0.99

$

In Stock, Qty 10

0

20

Bad Boy 025-7036-00

1/2 x 1/2 Spacer

$4.99

$

In Stock, only 2 left!

0

21

Bad Boy 201-1100-00

Stand Frame Support

$

$

Not available

22

Bad Boy 018-5043-00

3/8" x 1 1/4" Carriage Bolt

$1.49

$

In Stock, only 1 left!

0

23

Bad Boy 018-3001-00

5/8" x 5/8" Shoulder Bolt

$16.99

$

In Stock, Qty 8

0

24

Bad Boy 019-5038-00

5/8" Flat Washer

$1.99

$

In Stock, only 4 left!

0

25

Bad Boy 032-5052-00

Bronze Bushing - SF - 2024-8

$4.99

$

In Stock, Qty 6

0

26

Bad Boy 026-5040-00

Stand Plate for Stand On

$

$

Not available

27

Bad Boy 034-8045-00

Seat Spring

$21.99

$

Usually ships in 4-7 days

0

28

Bad Boy 014-8047-00

Spring Cap Cover

$2.49

$

In Stock, only 1 left!

0

29

Bad Boy 019-8051-00

5/16" Lock Washer

$0.99

$

In Stock, only 2 left!

0

30

Bad Boy 019-7040-00

1/4" Flat Washer

$0.99

$

In Stock, Qty 6

0

31

Bad Boy 013-8043-00

5/16" Nut

$0.99

$

In Stock, only 2 left!

0

32

Bad Boy 018-2006-00

5/16 x 1 1/4 Hex Bolt

$0.99

$

In Stock, Qty 5

0

33

Bad Boy 026-5020-00

Height Indicator Plate Stand On (Bolt on)

$11.99

$

Usually ships in 0 days

0

34

Bad Boy 025-5338-00

.502 ID X.75 OD X 1.500 Leng

$3.99

$

In Stock, only 2 left!

0

35

Bad Boy 018-2071-00

3/8 x 2 1/2 Hex Tap Bolt

$1.99

$

Usually ships in 4-7 days

0

36

Bad Boy 040-4075-00

Pin And Lanyard

$13.99

$

Usually ships in 4-7 days

0

37

Bad Boy 079-4000-00

Floor Panel Stand On

$

$

Currently unavailable

38

Bad Boy 019-6042-00

.360 ID Plastic Washer

$0.99

$

In Stock, only 1 left!

0

39

Bad Boy 013-8073-00

1/4" Nylock Nut

$0.99

$

In Stock, only 2 left!

0

40

Bad Boy 018-8040-00

1/4" x 3/4" Carriage Bolt

$1.99

$

Usually ships in 4-7 days

0

41

Bad Boy 030-3050-00

#10 x 1/2" Self Taping Screw

$0.99

$

In Stock, Qty 9

0

42

Bad Boy 029-4010-00

Button Bumper

$1.49

$

Usually ships in 4-7 days

0

43

Bad Boy 040-4060-00

Deck Height Pin-Stand On-New

$

$

Not available

44

Bad Boy 013-5202-00

3/8" Nylock Flange Nut

$1.99

$

In Stock, only 3 left!

0

45

Bad Boy 070-5210-00

Stand On Frame (48" Decks)

$

$

Not available

46

Bad Boy 034-1444-00

Rubber Cone-1621-153

$

$

Not available
