P 230 S - Shindaiwa Pole Saw / Pruner Fuel Tank Parts Diagram

Pole Saw / Pruner

Fuel Tank Parts Diagram

  • Title

7- 1

Echo 70192-85001

TANK ASSY, FUEL
(Superseded to P021030440)

$49.99

$

Usually ships in 2-4 days

0

2

Echo 20016-85112

TANK, FUEL
(Superseded to A350001530)

$18.99

$

Usually ships in 2-4 days

0

3

Echo 70168-85201

CAP ASSY, FUEL
(Superseded to A033000010)

$8.99

$

In Stock, only 1 left!

0

4

Echo 70168-85210

CAP, FUEL
(Superseded to A355000180)

$8.99

$

In Stock, only 1 left!

0

9

Echo 20000-85221

GASKET, FUEL CAP
(Superseded to V107000010)

$1.99

$

In Stock, Qty 18

0

10

Echo 20016-85310

PIPE, FUEL
(Superseded to V470001210)

$4.99

$

In Stock, Qty 13

0

11

Echo 20020-85540

CLIP Ø6
(Superseded to V490000500)

$1.49

$

In Stock, Qty 7

0

12

Echo 20016-85400

FILTER, FUEL 125-528
(Superseded to A369000070)

$9.99

$

In Stock, Qty 20+

0

13

Echo 20089-83311

PIPE, FUEL RETURN
(Superseded to V471002790)

$1.99

$

In Stock, Qty 17

0

14

Echo 20087-85340

CONNECTOR, PIPE
(Superseded to V186000270)

$3.49

$

In Stock, only 3 left!

0

15

Echo 20035-85522

VENT ASSY
(Superseded to A356000040)

$7.49

$

In Stock, Qty 20+

0

16

Echo 20016-12310

CLIP, VENT ASSY
(Superseded to A358000040)

$1.49

$

In Stock, only 4 left!

0

17

Echo 37013-85310

CLIP, SPRING Ø5.2
(Superseded to V490000510)

$1.49

$

In Stock, Qty 5

0

18

Echo 20020-85540

CLIP Ø6
(Superseded to V490000500)

$1.49

$

In Stock, Qty 7

0

19

Echo 20024-86120

CUSHION, FUEL TANK
(Superseded to V420002630)

$1.99

$

In Stock, Qty 11

0

20

Echo 62902-85320

GUARD, PLASTIC FUEL TANK
(Superseded to A175000220)

$14.99

$

In Stock, only 2 left!

0

21

Echo 11022-05180

BOLT M5×18
(Superseded to V203000540)

$1.49

$

In Stock, only 4 left!

0
