PB-230 LN - Echo Handheld Blower (SN: 07001001 - 07999999) Carburetor -- RB-K65 S/N: 07001001 - 07001600 Parts Diagram

Handheld blower with a 22.8 cc 2-stroke engine (EPA Phase II, 300-hour emissions durability). Runs on a 1:50 oil-mix, manufactured in 2006 by Echo, Inc., and is compatible with Tune-Up Kit 90153Y (fuel filter, air filter, optional pre-filter, spark plug).

Carburetor -- RB-K65 S/N: 07001001 - 07001600 Parts Diagram

  • Title

Echo A021000352

CARBURETOR - RB-K65
(Superseded to A021000780)

Note: SUPERSEDES:A021000351 CARBURETOR -- RB-K65, A021000350 CARBURETOR -- RB-K65

$105.99

$

Usually ships in 2-4 days

0

1

Echo 12534413931

SCREW

$2.99

$

In Stock, Qty 12

0

2

Echo P005000710

ROTOR COVER ASSY

$38.99

$

Usually ships in 2-4 days

0

3

Echo P005000120

NUT

$4.49

$

In Stock, only 2 left!

0

4

Echo P005000110

ADJUSTER, THROTTLE CABLE

$4.49

$

Usually ships in 2-4 days

0

5

Echo P005000180

SWIVEL

$4.99

$

Usually ships in 2-4 days

0

6

Echo P005000190

E-RING

$0.99

$

In Stock, only 3 left!

0

7

Echo P005000100

SCREW, IDLE ADJUST

$6.49

$

In Stock, only 2 left!

0

8

Echo P005000280

O-RING

$4.49

$

In Stock, only 3 left!

0

9

BODY, CARBURETOR

Note: NOT AVAILABLE SEPARATELY

$

$

Not available

10

Echo P005001000

GUIDE, ROLLER

$1.99

$

In Stock, only 4 left!

0

11

Echo P005000720

JET, MAIN

$3.49

$

Usually ships in 2-4 days

0

12

Echo P005000370

PLUG KIT

$

$

Not available

13

Echo P005000930

BODY ASSY, PURGE

$23.99

$

In Stock, only 1 left!

0

14

Echo P005000270

SCREW

$1.49

$

In Stock, Qty 20+

0

15

Echo 12538108660

BULB, PURGE
(Superseded to P005003120)

$7.49

$

In Stock, Qty 20+

0

16

Echo P005000250

RETAINER, PURGE BULB

$2.49

$

In Stock, Qty 14

0

17

Echo P005000260

SCREW, PURGE BULB RETAINER
(Superseded to 12531061830)

Note: PRIMING PUMP RETAINER

$0.99

$

In Stock, Qty 20+

0

18

Echo 12534252130

COVER, METERING DIAPHRAGM

$4.99

$

In Stock, only 2 left!

0

19

Echo 125344-52130

SCREW

$0.99

$

In Stock, Qty 10

0

20

Echo 125339-42030

SCREW

Note: METERING LEVER PIN

$0.99

$

In Stock, Qty 11

0

21

Echo P005000560

REBUILD KIT
(Superseded to P005002880)

Note: INCLUDES ITEMS 22-30

$19.99

$

Usually ships in 2-4 days

0

22

DIAPHRAGM, PUMP

$

$

Not available

23

GASKET, PUMP

$

$

Not available

24

STRAINER

$

$

Not available

25

SPRING, METERING LEVER

$

$

Not available

26

VALVE, INLET NEEDLE

$

$

Not available

27

LEVER, METERING

$

$

Not available

28

PIN, METERING LEVER

$

$

Not available

29

GASKET, METERING

$

$

Not available

30

DIAPHRAGM, METERING

$

$

Not available

31

Echo P005000550

GASKET / DIAPHRAGM KIT

Note: INCLUDES ITEMS 32-35

$9.49

$

In Stock, only 3 left!

0

32

DIAPHRAGM, PUMP

$

$

Not available

33

GASKET, PUMP

$

$

Not available

34

GASKET, METERING

$

$

Not available

35

DIAPHRAGM, METERING

$

$

Not available
