PP 255 - Poulan Pro Chainsaw Engine 225 Parts Diagram

Chainsaw

Engine 225 Parts Diagram

  • Title

1

Poulan 530015899

Screw

$6.49

$

In Stock, Qty 15

0

2

Poulan 530014362

Fuel Pick-up
(Superseded to 530095646)

$4.99

$

In Stock, Qty 20+

0

3

Poulan 534790500

Nut

$3.49

$

In Stock, Qty 6

0

4

Poulan 530069247

Fuel Line

$6.49

$

In Stock, Qty 20+

0

5

Poulan 530036141

Air Filter (Top)
(Superseded to 545057701)

$4.99

$

In Stock, Qty 17

0

6

Poulan 530015970

Screw

$6.49

$

Usually ships in 3-10 days

0

7

Poulan 530037478

Air Filter (Bottom)
(Superseded to 530059738)

$

$

Not available

8

Poulan 530035330

Carburetor Type 1,2,3,4
(Superseded to 545013503)

$50.99

$

In Stock, Qty 12

0

8

Poulan 530069629

Carburetor Type 5
(Superseded to 545013503)

Note: (Incl.Limiter Caps)

$50.99

$

In Stock, Qty 12

0

9

Poulan 530019172

Carb. Gasket

$6.49

$

In Stock, Qty 20+

0

10

Poulan 530037530

Carb. Grommet Type 1,2,3,4
(Superseded to 530037464)

$3.99

$

Usually ships in 3-10 days

0

10

Poulan 530037464

Carb. Grommet Type 5

$3.99

$

Usually ships in 3-10 days

0

11

Poulan 530015905

Screw
(Superseded to 530015814)

$6.49

$

In Stock, Qty 20+

0

12

Poulan 530037465

Carb. Adaptor

$

$

Not available

13

Poulan 530029814

Intake Sleeve

$13.99

$

In Stock, Qty 17

0

14

Poulan 530019177

Turbo Clean Seal

$

$

Not available

15

Poulan 530029813

Turbo Air Cleaner Ass'y.

$

$

Not available

16

Poulan 952030150

Spark Plug (CJ-7Y)

$3.49

$

In Stock, Qty 20+

0

17

Poulan 530016154

Screw

$3.99

$

In Stock, Qty 20+

0

18

Poulan 530069577

Cylinder Shield Kit

$

$

Not available

19

Poulan 530015406

Screw

$3.99

$

Usually ships in 3-10 days

0

20

Poulan 530047382

Handguard

$

$

Not available

21

Poulan 530019171

Impulse Seal
(Superseded to 530053435)

$4.99

$

In Stock, Qty 20+

0

22

Poulan 530015895

Screw

$3.99

$

Usually ships in 3-10 days

0

23

Poulan 530036129

Switch Wire Ass'y.
(Superseded to 530037467)

$

$

Not available

24

Poulan 530039143

Ignition Module
(Superseded to 575803501)

$18.99

$

In Stock, Qty 20+

0

25

Poulan 530015938

Muffler Bolt 5 mm
(Superseded to 530016170)

$

$

Not available

25

Poulan 530016170

Muffler Bolt 6 mm

$

$

Not available

26

Poulan 530036099

Muffler Cover
(Superseded to 530037249)

$4.99

$

Usually ships in 3-10 days

0

27

Poulan 530037813

Spark Screen

$4.99

$

In Stock, only 2 left!

0

28

Poulan 530036102

Diffuser

$

$

Not available

29

Poulan 530015902

Bolt

$4.99

$

In Stock, Qty 7

0

30

Poulan 530037248

Muffler Body

$10.99

$

Usually ships in 3-10 days

0

31

Poulan 530029982

Piston Ring
(Superseded to 537400001)

$29.99

$

In Stock, only 3 left!

0

32

Poulan 530015697

Piston Pin Retainer

$6.49

$

In Stock, Qty 6

0

33

Poulan 530069414

Cylinder Kit
(Superseded to 530069941)

Note: (Incl. 33 & 36)

$

$

Not available

34

Poulan 530029794

C'shaft & Rod Ass'y.
(Superseded to 503920801)

$

$

Not available

35

Poulan 530032117

Piston Pin Bearing

$

$

Not available

36

Poulan 530015897

Screw

$6.49

$

In Stock, Qty 19

0

37

Poulan 530019170

C'shaft Seal

$6.49

$

In Stock, Qty 13

0

38

Poulan 530032118

C'shaft Bearing

$

$

Not available

39

Poulan 530069454

Piston Kit

Note: (Incl. 31,32,35& Pin)

$47.30

$

Usually ships in 3-10 days

0

40

Poulan 530069416

Muffler Kit

Note: (Incl. 25,26,28,30)

$

$

Not available

41

Poulan 530037652

Heat Insulator

$

$

Not available

42

Poulan 530037640

Muffler Plate

$

$

Not available

43

Poulan 530019205

Muffler Gasket

$6.49

$

In Stock, only 4 left!

0

43

Poulan 530031135

Scrench
(Superseded to 530031163)

Note: Not Shown

$9.99

$

In Stock, Qty 17

0

43

Poulan 530083080

Operator Manual U.S.

Note: Not Shown

$

$

Not available

43

Poulan 530083110

Operator Manual Canada

Note: Not Shown

$

$

Not available

43

Poulan 530069316

Clutch Drum (Rim)

Note: Not Shown

$

$

Not available

43

Poulan 530031136

Worm Gear Puller

Note: Not Shown

$

$

Not available

Poulan 530031112

Clutch Assy Tool

Note: Not Shown

$14.99

$

In Stock, only 4 left!

0

Poulan 530038638

Decal - Warning U.S.

Note: Not Shown

$

$

Not available

Poulan 530036394

Decal - Warning Canada

Note: Not Shown

$

$

Not available
