PP 285 - Poulan Pro Chainsaw EXTERNAL POWER UNIT Parts Diagram

Chainsaw

EXTERNAL POWER UNIT Parts Diagram

  • Title

1

Poulan 530027732

Retainer Mount

$3.99

$

Usually ships in 3-10 days

0

2

Poulan 530016057

Screw

$4.99

$

In Stock, only 3 left!

0

3

Poulan 530027732

Chain Catcher Retainer-Serv. Ref. 1

$3.99

$

Usually ships in 3-10 days

0

4

Poulan 530027399

Carb. Cover Bumper

$3.99

$

In Stock, only 1 left!

0

5

Poulan 530027392

Lower Isolator

$

$

Not available

6

Poulan 530010877

Type I

$

$

Not available

6

Poulan 530069391

Type II

$

$

Not available

7

Poulan 530027394

Cylindrical Mount

$14.99

$

Usually ships in 3-10 days

0

8

Poulan 530027187

Isolator Limiter

$3.99

$

In Stock, only 1 left!

0

9

Poulan 530015715

Type I

$3.99

$

In Stock, only 3 left!

0

9

Poulan 530015871

Type II
(Superseded to 530015650)

$

$

Not available

10

Poulan 530027733

Chain Catcher-Serv. Ref. 1

$

$

Not available

11

Poulan 530015702

"C" Clip

$

$

Not available

12

Poulan 530010845

Fuel Cap Ass'y.

$

$

Not available

13

Poulan 530027181

Handguard

$

$

Not available

14

Poulan 530027191

Bracket

$4.99

$

Usually ships in 3-10 days

0

15

Poulan 530015598

Screw

$

$

Not available

16

Poulan 530027139

(Two piece design)

$2.99

$

Usually ships in 3-10 days

0

16

Poulan 530029666

(One piece design)

$

$

Not available

17

Poulan 530024772

Throttle Lock Spring

$4.99

$

In Stock, only 1 left!

0

18

Poulan 530015716

Screw

$

$

Not available

19

Poulan 530015406

Screw

$3.99

$

Usually ships in 3-10 days

0

20

Poulan 530069279

Cylinder Shield Kit (Inc.54.)

$

$

Not available

21

Poulan 530027178

Carb. Cover

$

$

Not available

22

Poulan 530015871

Screw
(Superseded to 530015650)

$

$

Not available

23

Poulan 530027134

Trigger Latch Spring

$2.49

$

Usually ships in 3-10 days

0

24

Poulan 530027133

Throttle Trigger

$3.99

$

Usually ships in 3-10 days

0

25

Poulan 530027271

Grommet

$

$

Not available

26

Poulan 530027121

Bracket

$

$

Not available

27

Poulan 530069217

Gasket Set

$

$

Not available

28

Poulan 530035201

Carburetor (HDA-49)

$

$

Not available

29

Poulan 530023664

Air Filter Plate

$3.99

$

Usually ships in 3-10 days

0

30

Poulan 530015735

Carb. Mounting Stud

$

$

Not available

31

Poulan 530010892

Model 285

$

$

Not available

31

Poulan 530010855

Model 305 & 335

$

$

Not available

32

Poulan 530027135

Throttle Lockout

$

$

Not available

33

Poulan 530027207

Rear Handle Cover

$

$

Not available

34

Poulan 530027073

Throttle Wire

$6.49

$

In Stock, only 1 left!

0

35

Poulan 530027075

Choke Knob

$3.99

$

Usually ships in 3-10 days

0

36

Poulan 530027393

Type I

$10.99

$

In Stock, only 1 left!

0

36

Poulan 530036962

Type II

$

$

Not available

37

Poulan 530001543

Nut

$

$

Not available

38

Poulan 530015701

Dowel Pin

$2.23

$

In Stock, only 1 left!

0

39

Poulan 530015724

Screw

$

$

Not available

40

Poulan 530069216

Line Kit (Bulk 530-008133)

$6.49

$

In Stock, Qty 20+

0

41

Poulan 530014199

Fuel Filter Ass'y.
(Superseded to 530095646)

$4.99

$

In Stock, Qty 20+

0

42

Poulan 530039129

Grommet

$

$

Not available

43

Poulan 530069225

Switch Kit

$

$

Not available

44

Poulan 530027138

Lead Wire Ass'y.

$

$

Not available

45

Poulan 530015802

Screw
(Superseded to 530015598)

$

$

Not available

46

Poulan 530027202

Screw Retainer

$2.49

$

Usually ships in 3-10 days

0

47

Poulan 530025539

Impulse Fitting

$

$

Not available

48

Poulan 530024475

Vent Fitting

$6.49

$

In Stock, Qty 20+

0

49

Poulan 530026119

Check Valve

$4.49

$

In Stock, Qty 18

0

50

Poulan 530031111

Hex Key
(Superseded to 530031159)

$4.99

$

In Stock, only 1 left!

0

51

Poulan 530027339

Vent Plug

$

$

Not available

52

Poulan 530025922

Air Box Plug

$3.99

$

Usually ships in 3-10 days

0

53

Poulan 530027341

Clamp

$4.99

$

Usually ships in 3-10 days

0

54

Poulan 530027888

Reflector

$

$

Not available

55

Poulan 952069253

Carb. Cover Winter Kit

$

$

Not available

56

Poulan 530069297

Bracket Kit-Service Ref. 1

$

$

Not available

57

Poulan 530015710

Screw

$

$

Not available

58

Poulan 530015875

Screw

$4.99

$

In Stock, only 3 left!

0

59

Poulan 530015562

Washer

$2.49

$

In Stock, only 1 left!

0

60

Poulan 530015123

Washer-Typell Only

$4.99

$

In Stock, only 4 left!

0

61

Poulan 530037009

AV Strap-Typell Only

$

$

Not available

62

Poulan 530037012

Strap Retainer Plate-Type II Only

$4.99

$

In Stock, Qty 9

0

63

Poulan 530069384

Isolator Ass'y. Kit-Type II Only

$

$

Not available

64

Poulan 530069297

Isolator Repair Kit-Type II Only

$

$

Not available
