PP WT 60022 (961720006-00) - Poulan Pro Wheeled Trimmer (2009-11) Engine Parts Diagram

Wheeled Trimmer

Engine Parts Diagram

  • Title

1

Engine, Briggs & Stratton, Model No. 122T02-1382-B1

Note: (Order parts from Briggs & Stratton)

$

$

Not available

2

Electrolux/AYP 150406

Bolt, Engine Mounting 3/8-16
(Superseded to 532150406)

$7.49

$

In Stock, only 3 left!

0

3

Electrolux/AYP 179466

Pulley, Engine
(Superseded to 532184130)

$

$

Not available

4

Electrolux/AYP 88348

Washer, Flat
(Superseded to 532088348)

$7.49

$

In Stock, Qty 11

0

8

Electrolux/AYP 169821X479

Handle, Lower
(Superseded to 532186754)

$20.99

$

Usually ships in 3-10 days

0

9

Electrolux/AYP 428867

Screw, Hex Washer Head 5/16-18 x 3/4
(Superseded to 532428867)

$6.49

$

In Stock, Qty 14

0

10

Electrolux/AYP 169797X479

Handle, Upper
(Superseded to 532186755)

$31.99

$

Usually ships in 3-10 days

0

11

Electrolux/AYP 170980

Bolt, Handle
(Superseded to 532170980)

$6.49

$

In Stock, Qty 6

0

12

Electrolux/AYP 189713X428

Knob, Handle
(Superseded to 532185577)

$9.49

$

In Stock, Qty 20+

0

15

Electrolux/AYP 179751

Handle Adjuster Assembly
(Superseded to 532179751)

$21.99

$

Usually ships in 3-10 days

0

16

Electrolux/AYP 194788

Guide, Rope
(Superseded to 532194788)

$18.99

$

In Stock, only 2 left!

0

18

Electrolux/AYP 66426

Wire Tire
(Superseded to 532007192)

$9.49

$

Usually ships in 3-10 days

0

19

Electrolux/AYP 176983X421

Control Bar
(Superseded to 532436354)

$

$

Not available

20

Electrolux/AYP 417238

Throttle Control
(Superseded to 586861201)

$37.99

$

In Stock, only 4 left!

0

21

Electrolux/AYP 158755

Screw, Hex Washer Head
(Superseded to 532158755)

$

$

Not available

22

Electrolux/AYP 169787

Axle Shaft Assembly
(Superseded to 592930001)

$22.99

$

In Stock, only 2 left!

0

23

Electrolux/AYP 428867

Screw, Hex Washer Head 5/16-18 x 3/4
(Superseded to 532428867)

$6.49

$

In Stock, Qty 14

0

24

Electrolux/AYP 169823

Washer, Axle
(Superseded to 532169823)

$11.99

$

Usually ships in 3-10 days

0

25

Electrolux/AYP 197480

O-Ring
(Superseded to 532197480)

$7.49

$

In Stock, Qty 11

0

26

Electrolux/AYP 195012X428

Wheel, 12 x 1-3/4
(Superseded to 581010301)

$22.99

$

Usually ships in 3-10 days

0

27

Electrolux/AYP 409149

Locknut, Hex 3/8-16
(Superseded to 532409149)

$4.99

$

In Stock, Qty 20+

0

28

Electrolux/AYP 181699

Drive Control Cable
(Superseded to 532181699)

$34.99

$

In Stock, only 3 left!

0

29

Electrolux/AYP 406678

Decal, Warning
(Superseded to 532406678)

$36.99

$

Usually ships in 3-10 days

0

30

Electrolux/AYP 178365

Decal, Warning
(Superseded to 532178365)

$15.99

$

Usually ships in 3-10 days

0

31

Electrolux/AYP 172221X479

Bracket, Support, Axle Shaft
(Superseded to 532426297)

$4.99

$

Usually ships in 3-10 days

0

33

Electrolux/AYP 132004

Nut, Hex

$

$

Not available

34

Electrolux/AYP 429930X004

Bracket, Upstop
(Superseded to 532430034)

$

$

Not available

35

Electrolux/AYP 750634

Screw #10-24 x 5/8
(Superseded to 532750634)

$6.49

$

In Stock, only 3 left!

0

36

Electrolux/AYP 851084

Bolt, Hex Head
(Superseded to 532851084)

$4.99

$

In Stock, Qty 20+

0

37

Electrolux/AYP 850263

Washer, Lock
(Superseded to 810040600)

$1.99

$

Usually ships in 3-10 days

0

38

Electrolux/AYP 851074

Washer, Flat, Hardened
(Superseded to 532851074)

$4.99

$

In Stock, Qty 20+

0

38

Electrolux/AYP 431477

Manual, Replacement Parts
(Superseded to 917431477)

$4.99

$

Usually ships in 3-10 days

0

38

Electrolux/AYP 177817

Manual, Operator's, English
(Superseded to 917177817)

$4.99

$

Usually ships in 3-10 days

0

38

Electrolux/AYP 180102

Manual, Operator's, French

$3.49

$

Usually ships in 3-10 days

0
