PR 100 (961820015-03) - Poulan Pro Snow Thrower (2017-01) AUGER HOUSING & IMPELLER Parts Diagram

Snow Thrower

AUGER HOUSING & IMPELLER Parts Diagram

  • Title

1

Poulan 532442759

AUGER.BLADE.SS.SNOW

$80.99

$

Usually ships in 3-10 days

0

2

Poulan 580855501

SUPPORT.BEARING.SINGLE.STAGE.B

$8.99

$

Usually ships in 3-10 days

0

3

Poulan 532437622

BEARING.BALL.MANDREL
(Superseded to 532110485)

$10.99

$

In Stock, Qty 20+

0

4

Poulan 812000028

Ring Retainer # 5100-62 (AYP part number)
(Superseded to 532002267)

$7.49

$

In Stock, Qty 16

0

5

Poulan 817060408

Screw, Hex Head, Thread Cutting 1/4-20 x 1/2 (AYP part number)

$4.99

$

Usually ships in 3-10 days

0

6

Poulan 532437617

WELDMENT.AUGER.SINGLE.STAGE.BL

$68.99

$

Usually ships in 3-10 days

0

7

Poulan 580855401

PLATE.CENTER.BLADE.BLACK
(Superseded to 532434777)

$5.99

$

Usually ships in 3-10 days

0

8

Poulan 532437620

PIN.ROLL.3/16 X 1-1/4

$4.99

$

Usually ships in 3-10 days

0

9

Poulan 532199687

SCREW

$4.99

$

Usually ships in 3-10 days

0

10

Poulan 872110407

BOLT.CARRIAGE.1/4-20 X 7/8

$4.99

$

Usually ships in 3-10 days

0

11

Poulan 532191730

NUT.HEX.FLANGE.1/4

$7.49

$

In Stock, Qty 7

0

12

Poulan 532132004

NUT
(Superseded to 873800400)

$3.99

$

Usually ships in 3-10 days

0
