PRO Z 900 KW 972-SDL (53RLLVUY050) - Cub Cadet 72" Pro Z Series Zero-Turn Mower, Dually, Kawasaki (2024) Brake Handle Parts Diagram

72" Pro Z Series Zero-Turn Mower, Dually, Kawasaki

Brake Handle Parts Diagram

  • Title

1

Cub Cadet 680E00436

PIVOT TUBE ASSEMBLY

$62.99

$

Usually ships in 3-6 days

0

2

Cub Cadet 680E02787

BRAKE PIVOT SHAFT

$39.99

$

Usually ships in 0 days

0

3

Cub Cadet 680E02804

ACTUATOR BRACKET

$77.99

$

Usually ships in 0 days

0

4

Cub Cadet 703-10480A

PARKING BRAKE LEVER

Note: *CHOOSE COLOR WHEN ORDERING*

Variations

703-10480A-4021

Cub Cadet 703-10480A-4021

PARKING BRAKE LEVE - CUB YELLOW 2 (4021)

$35.99

$

Usually ships in 3-6 days

0

$28.99

$

Usually ships in 3-6 days

0

5

Cub Cadet 703-10540A

BRAKE LEVER PIVOT COVER

Note: *CHOOSE COLOR WHEN ORDERING*

Variations

703-10540A-4021

Cub Cadet 703-10540A-4021

BRAKE LEVER PIVOT - CUB YELLOW 2 (4021)

$31.99

$

Usually ships in 3-6 days

0

$25.99

$

Usually ships in 3-6 days

0

6

Cub Cadet 703E10920A

3-POLE SWITCH BRACKET

$26.99

$

In Stock, only 2 left!

0

7

Cub Cadet 703E28780

BRAKE ARM PLATE

$23.99

$

Usually ships in 0 days

0

8

Cub Cadet 703E28785

CABLE BRACKET

$24.99

$

Usually ships in 0 days

0

9

Cub Cadet 703-28786

BRAKE LEVER COVER

Note: *CHOOSE COLOR WHEN ORDERING*

$36.99

$

Usually ships in 0 days

0

10

Cub Cadet 703E28960

BYPASS LEVER BRACKET

$7.99

$

Usually ships in 0 days

0

11

Cub Cadet 710-0276

CARRIAGE BOLT 5/16-18 x 1.00

$4.49

$

In Stock, Qty 20+

0

12

Cub Cadet 710-0347

HEX SCREW 3/8-16 x 1.75 GR5

$5.49

$

In Stock, Qty 20+

0

13

Cub Cadet 710-0395

HEX SCREW 5/16-18 x 2.25 GR5

$4.99

$

In Stock, Qty 11

0

14

Cub Cadet 710-04683C

SCREW 3/8-16 x 1

$6.99

$

In Stock, Qty 20+

0

15

Cub Cadet 710-0599

SCREW 1/4-20 X.500

$4.49

$

In Stock, Qty 20+

0

16

Cub Cadet 710-06534

EYE BOLT SPRING GUIDE 1/4-20

$11.99

$

Usually ships in 3-6 days

0

17

Cub Cadet 710-0805A

SCREW 5/16-18 x 1.5 LG

$4.99

$

In Stock, Qty 20+

0

18

Cub Cadet 710-1880

SCREW 5/16-18 x .750

$4.99

$

Usually ships in 3-6 days

0

19

Cub Cadet 710-3168

CARRIAGE BOLT 3/8-16 x 1.00 GR5

$4.49

$

In Stock, Qty 20+

0

20

Cub Cadet 711-11552

ACTUATOR BYPASS SHAFT

$32.99

$

Usually ships in 0 days

0

21

Cub Cadet 712-04063

FLANGE LOCK NUT 5/16-18

$4.49

$

In Stock, Qty 20+

0

22

Cub Cadet 712-04064

FLANGE LOCK NUT

$4.49

$

In Stock, Qty 20+

0

23

Cub Cadet 712-04065

NUT

$4.49

$

In Stock, Qty 20+

0

24

Cub Cadet 712-3008

HEX JAM NUT 3/8-16 GR5

$4.99

$

In Stock, Qty 12

0

25

Cub Cadet 712-3046

HEX NUT TOP LOCK 5/16-18 GR 8

$7.49

$

Usually ships in 3-6 days

0

26

Cub Cadet 714-04040

BOW TIE COTTER PIN 1/4-5/16

$1.49

$

In Stock, Qty 20+

0

27

Cub Cadet 720-04139B

GRIP

$19.99

$

In Stock, Qty 6

0

28

Cub Cadet 726-0475

HOSE CLAMP 1.0"

$14.99

$

Usually ships in 3-6 days

0

29

Cub Cadet 732-08273

EXTENSION SPRING .65 OD x 2.65 LG

$6.49

$

Usually ships in 3-6 days

0

30

Cub Cadet 736-0159

FLAT WASHER

$4.49

$

In Stock, Qty 20+

0

31

Cub Cadet 736-0258

FLAT WASHER .385 x 1.00 x .135

$4.99

$

In Stock, Qty 20+

0

32

Cub Cadet 736-0264

FLAT WASHER

$7.49

$

In Stock, only 2 left!

0

33

Cub Cadet 736-04117

FLAT WASHER 1.0 OD:.331 ID

$3.49

$

In Stock, Qty 20+

0

34

Cub Cadet 736-0621

WAVE WASHER .785X1.00X.012

$18.99

$

In Stock, only 2 left!

0

35

Cub Cadet 741-04458

FLANGE BEARING .625 X .75 X .75

$2.99

$

Usually ships in 0 days

0

36

Cub Cadet 741-04555

SLEEVE BEARING

$17.99

$

In Stock, only 1 left!

0

37

Cub Cadet 746P06998

PARK BRAKE CABLE

$41.99

$

Usually ships in 0 days

0

38

Cub Cadet 747-11793

BYPASS ROD

$39.99

$

Usually ships in 0 days

0

39

Cub Cadet 750-04194

SPACER

$6.99

$

Usually ships in 3-6 days

0

40

Cub Cadet 750-06515

SPACER

$33.99

$

Usually ships in 3-6 days

0
