RD-1750 (13B4516N190) - White Outdoor 42" Lawn Tractor (2004) Steering Parts Diagram

42" Lawn Tractor

Steering Parts Diagram

  • Title

?23

783-1335A

BRKT:SUPT:STRG:500

$

$

Not available

22

White Outdoor 741-0656

BRG:HEX FLNG 5/8
(Superseded to 941-0656A)

$4.99

$

In Stock, Qty 20+

0

21

White Outdoor 741-0475

PLASTIC BUSHING .380 ID
(Superseded to 941-0475)

$3.99

$

In Stock, Qty 20+

0

20

White Outdoor 738-1001A

SHF:STRG:.625 OD x 24.25 LG

$69.99

$

In Stock, Qty 6

0

19

White Outdoor 738-0372B

SPCR:SHLDR:1.00 X .38 X .38

$8.99

$

In Stock, Qty 20+

0

18

737-3007

GRES:ALVANIA EP 2

$

$

Not available

17

White Outdoor 736-3084

WASH:FLAT:.510 X 1.120 X .060

$4.49

$

In Stock, Qty 20+

0

16

White Outdoor 736-3004

WASH:FL:.406IDX.875ODX.105

$4.49

$

In Stock, Qty 19

0

15

736-0770

WASH:FLAT:13 X 19 X .3 DIN 988

$

$

Not available

14

White Outdoor 736-0242

WASH:BELL:.340 X.872 X.060

$3.99

$

In Stock, Qty 20+

0

13

White Outdoor 736-0169

WASH:LOCK:3/8:REGULAR DUTY

$3.49

$

In Stock, Qty 20+

0

?12

White Outdoor 723-0448A

B/JNT:7/16-20:LOCK
(Superseded to 923-0448A)

$22.99

$

In Stock, Qty 20+

0

11

White Outdoor 717-1554

GEAR:PNION:STRG

$10.99

$

In Stock, Qty 20+

0

10

White Outdoor 717-1550E

GEAR:STRG:11/90 RATIO
(Superseded to 717-1550F)

$65.99

$

In Stock, Qty 20+

0

9

White Outdoor 712-3004A

NUT:FLGLK:5/16-18:GR5:SD LK

$3.49

$

In Stock, Qty 20+

0

8

White Outdoor 712-0459

NUT:FLGLK:7/16-20:GRB:LOCK

$4.49

$

In Stock, Qty 20+

0

7

White Outdoor 712-0431

NUT:FLGLK:3/8-16:GRF:TOP LK
(Superseded to 912-0431)

$4.99

$

In Stock, Qty 20+

0

6

White Outdoor 712-0241

NUT:HEX:3/8-24:GR5

$4.49

$

In Stock, Qty 20+

0

5

White Outdoor 712-0240

NUT:JAM:7/16-20:GR2
(Superseded to 912-0240)

$3.99

$

In Stock, Qty 20+

0

4

711-1776A

LINK:DRAG:RH

$

$

Not available

3

711-1775A

LINK:DRAG:LH

$

$

Not available

2

White Outdoor 710-0643

HHCS:5/16-18:1.00:GR5:LOCK

$6.49

$

In Stock, Qty 20+

0

1

White Outdoor 710-0514

HHCS:3/8-16:1.00:GR5:STD

$3.99

$

In Stock, Qty 20+

0
