Renegade Diesel - Bad Boy Zero-Turn Mower (2019) REAR COVER & HYDRAULIC COOLERS Parts Diagram

Zero-Turn Mower

REAR COVER & HYDRAULIC COOLERS Parts Diagram

  • Title

9

Bad Boy 013-2050-00

1/4-20 Hex flang lock nut

$1.49

$

In Stock, only 2 left!

0

13

Bad Boy 013-5202-00

3/8" Nylock Flange Nut

$1.99

$

In Stock, Qty 15

0

21

Bad Boy 013-8050-00

1/2-13 Nylon Flange Nut

$1.99

$

In Stock, Qty 20+

0

22

Bad Boy 013-8051-00

1/4" Wing Nut

$0.99

$

In Stock, Qty 5

0

32

Bad Boy 014-5063-00

2019 Horizontal Battery Hold Down Cover

$11.99

$

Usually ships in 4-7 days

0

52

Bad Boy 018-0040-00

1/2" x 8 1/2 GR 5 Hex Bolt

$7.49

$

In Stock, Qty 13

0

54

Bad Boy 018-0044-00

3/8" x 2 1/2" Carriage Bolt

$3.49

$

Usually ships in 4-7 days

0

76

Bad Boy 018-4702-00

1/4-20 x 1-1/4 GR 5 Hex Bolt

$0.99

$

Usually ships in 4-7 days

0

95

Bad Boy 018-8051-00

1/4" x 1" Carriage Bolt

$1.99

$

Usually ships in 4-7 days

0

96

Bad Boy 018-8052-00

1/4" x 3/4" Hex Bolt

$0.99

$

Usually ships in 4-7 days

0

110

Bad Boy 019-7040-00

1/4" Flat Washer

$0.99

$

In Stock, Qty 6

0

131

Bad Boy 025-0028-00

2019 Rear Vertical Pulley Spacer

$9.99

$

In Stock, only 2 left!

0

134

Bad Boy 025-5203-00

Spacer 3/4 OD x 1/2 ID x 3\4 Length

$3.49

$

In Stock, Qty 15

0

138

Bad Boy 026-2224-00

2019 Horizontal Suspension Rear Cover

$193.99

$

Usually ships in 4-7 days

0

150

Bad Boy 029-7038-00

8" Rubber Bumper

$30.99

$

Usually ships in 4-7 days

0

172

Bad Boy 033-7027-00

2019 Outlaw Horizontal Rear V Pulley

$49.99

$

In Stock, Qty 5

0

212

Bad Boy 064-4000-00

Red Battery Cable - Diesel

$25.99

$

Usually ships in 4-7 days

0

213

Bad Boy 064-4001-00

Black Battery Cable - Diesel

$23.99

$

Usually ships in 4-7 days

0

218

Bad Boy 067-8052-19

Renegade Oil Cooler Assembly

$75.99

$

Usually ships in 4-7 days

0

223

Bad Boy 068-8050-00

Battery - Diesel/Renegade Models PF-516

$

$

Not available

230

Bad Boy 070-5374-19

2019 Horizontal Diesel Frame

$

$

Currently unavailable

218.1

Bad Boy 067-8052-00

2019 12" Oil Cooler With Fittings

$66.99

$

Usually ships in 4-7 days

0

218.2

Bad Boy 051-8063-14

3/8" Clear Hose

$6.49

$

Usually ships in 4-7 days

0

218.3

Bad Boy 051-8063-24

3/8" Clear Hose

$13.99

$

Usually ships in 4-7 days

0

218.4

Bad Boy 072-8065-00

3/8" Hose Clamp

$1.49

$

In Stock, only 2 left!

0
